Cable XLPE 50mm 3 Core+Earth | UV Stabilised Orange Sheath | 1000M Length | by Electra Cables
Cable XLPE 50mm 3 Core+Earth is designed for underground power distribution and industrial electrical installations. With a UV stabilised orange sheath and low smoke zero halogen properties, this cable ensures safety and durability in demanding environments. Ideal for large installations, it offers superior electrical performance and high current carrying capacity, making it a reliable choice for construction sites and infrastructure projects.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cable XLPE 50mm 3 Core+Earth | UV Stabilised Orange Sheath | 1000M Length | by Electra Cables
Brand: Electra Cables
SKU: XLPE3500E-BORE
Alternatively Known As: 50mm 3 Core + Earth XLPE Cable, 50mm 4 Core XLPE Cable, 50mm Mains Power Cable, Heavy Duty Orange Power Cable, Underground Power Cable 50mm
Technical Specifications
- Conductor: Stranded copper
- Insulation: Cross-linked polyethylene (XLPE)
- Sheath: UV stabilised orange PVC
- Configuration: 3 core + earth
- Nominal Area: 50mm²
- Voltage Rating: 0.6/1kV
- Length: 1000 metres
- Operating Temperature: -15°C to +90°C
- Standards: AS/NZS 5000.1
- Flame Retardant: Yes
- Low Smoke Zero Halogen: Yes
- Dimensions (H x L x W): 60mm x 1000000mm x 60mm
- Weight: 1200 kg
Key Features
- XLPE insulation for superior electrical and thermal performance
- 3 core plus earth configuration for enhanced safety
- UV stabilised orange sheath for outdoor and underground use
- Low smoke, zero halogen (LSZH) properties
- High current carrying capacity
- 1000 metre continuous length for large installations
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 Wiring Rules and local regulations.
Applications
- Underground power distribution
- Industrial and commercial electrical installations
- Mains and submains power supply
- Construction sites
- Infrastructure projects
Standards & Compliance
- Complies with AS/NZS 5000.1 for power cables with extruded insulation and sheath
Environmental Benefits
- Low smoke, zero halogen (LSZH) sheath reduces toxic emissions in case of fire
- UV stabilised for long outdoor life, reducing replacement frequency
- Durable construction minimises waste from frequent replacements
Warranty Information
12 months manufacturer's warranty against defects in materials and workmanship.
Available Now
Available for immediate purchase. Ideal for underground power distribution, industrial, and commercial electrical installations.
