Cablofil 316L Stainless Steel Wire Cable Tray Cover | 300mm Width | 2m Length | Halogen Free | @Each of 1 | by Cablofil
Cablofil 316L Stainless Steel Wire Cable Tray Cover is designed for effective cable management in industrial and commercial settings. With a width of 300mm and a length of 2m, this cover is made from high-quality 316L stainless steel, ensuring excellent corrosion resistance and durability. Ideal for protecting cables from dust and mechanical damage, it can be easily fitted using integral tabs or optional clips, making it a reliable choice for your cable management needs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: 316L Stainless Steel, pickled surface
- Width: 300 mm
- Length: 2000 mm
- Material Thickness: 0.6 mm
- Suitable for wire mesh trays only
- Type of fastening: Cover clamp with integral tabs or optional clips
- Operating Temperature: -20°C to 120°C
- Storage Temperature: -20°C to 120°C
- Halogen free
- Dimensions (H x L x W): 20mm x 2000mm x 300mm
- Weight: 3.5 kg
Key Features
- Made from high-quality 316L stainless steel for excellent corrosion resistance
- Supplied in 2 meter lengths with a width of 300mm
- Can be fitted directly using integral tabs or optional clips
- Material thickness of 0.6 mm
- Halogen free
- Operating temperature range from -20°C to 120°C
- Pickled stainless steel surface for enhanced durability
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with cable management systems to ensure secure fitting and compliance with safety standards.
Applications
- Suitable for wire mesh cable trays in industrial and commercial electrical installations
- Protects cables from dust, debris, and mechanical damage
- Used in environments requiring corrosion resistance and durability
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Made from recyclable stainless steel material
- Long service life reduces the need for frequent replacements
- Halogen free, reducing harmful emissions in case of fire
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil for specific warranty details.
Available Now
The Cablofil 316L Stainless Steel Wire Cable Tray Cover 300mm x 2m Length is available for immediate purchase, ideal for industrial and commercial cable management applications.
