Cablofil 316L Stainless Steel Wire Cable Tray | Flexible G-Shape | 50mm x 50mm | @Each of 1 | by Cablofil
The Cablofil 316L Stainless Steel Wire Cable Tray is designed for efficient cable management in industrial and commercial settings. With a flexible G-shape profile and superior corrosion resistance, it operates effectively in temperatures ranging from -20°C to 120°C. Ideal for corrosive environments, this cable tray ensures natural ventilation and lightweight handling, making it perfect for complex installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cablofil 316L Stainless Steel Wire Cable Tray | Flexible G-Shape | 50mm x 50mm | @Each of 1 | by Cablofil
Brand: Cablofil
SKU: CM430114
Alternatively Known As: Stainless Steel Wire Mesh Cable Tray, Flexible Cable Tray, Stainless Steel Cable Ladder, Wire Basket Tray
Technical Specifications
- Profile shape: G-shape
- Width: 50 mm
- Height: 50 mm
- Length: 3000 mm
- Usable cross section: 2500 mm²
- Material: Stainless steel 316L (1.4404)
- Surface protection: Pickled and passivated
- Operating temperature: -20°C to 120°C
- Storage temperature: -20°C to 120°C
- Weight: 0.4018 kg/m
- Dimensions (H x L x W): 50mm x 3000mm x 50mm
- Weight: 1.2 kg
Key Features
- Made from high-quality stainless steel 316L (1.4404) for superior corrosion resistance
- Flexible wire cable tray with G-shape profile
- Natural ventilation for greater cable efficiency
- Pickled and passivated surface protection
- Operating temperature range from -20°C to 120°C
- Lightweight at approximately 0.4 kg per meter
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with cable management systems and stainless steel handling to ensure safety and compliance.
Applications
- Industrial cable management
- Commercial electrical installations
- Corrosive environments requiring stainless steel cable trays
- Flexible cable routing in complex installations
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacement
- Corrosion resistance minimizes environmental contamination
- Supports efficient cable management reducing energy losses
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil warranty terms for details.
Available Now
The Cablofil 316L Stainless Steel Wire Cable Tray Flexible 50mm x 50mm x 3m Length is available for immediate purchase, ideal for industrial and commercial cable management applications.
