Cablofil Hot Dip Galvanised Steel Cable Tray Support Rail | 600mm Length | 1 kN Load Capacity | Halogen Free | @Each of 1 | by Cablofil
The Cablofil Hot Dip Galvanised Steel Cable Tray Support Rail is designed for robust cable management, featuring a 600mm length and a load-bearing capacity of 1 kN. Ideal for both floor and wall mounting, this rail is made from corrosion-resistant hot-dip galvanised steel and is halogen-free, ensuring safety and compliance in industrial and commercial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cablofil Hot Dip Galvanised Steel Cable Tray Support Rail | 600mm Length | 1 kN Load Capacity | Halogen Free | @Each of 1 | by Cablofil
Brand: Cablofil
SKU: CM013603
Alternatively Known As: Steel Cable Tray Support Rail, Galvanised Cable Tray Support, Cable Tray Mounting Rail
Technical Specifications
- Length: 594 mm
- Width: 68 mm
- Height: 25 mm
- Slit width: 25 mm
- Material thickness: 1.5 mm
- Profile shape: S-profile
- Type of perforation: Back perforated
- Hole width: 8.5 mm
- Load bearing capacity: 1 kN
- Material: Steel
- Surface protection: Hot-dip galvanised
- Operating temperature range: -20°C to 120°C
- Halogen free: Yes
- Dimensions (H x L x W): 25mm x 594mm x 68mm
- Weight: 1.2 kg
Key Features
- Hot-dip galvanised steel construction for corrosion resistance
- S-profile shape with back perforation
- Load bearing capacity of 1 kN
- Suitable for operating temperatures from -20°C to 120°C
- Halogen free material
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with cable tray systems and structural mounting to ensure safety and compliance.
Applications
- Floor mounting for cable trays
- Wall mounting for cable trays
- Trapeze mounting for cable trays
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Hot-dip galvanised coating extends product life reducing replacement frequency and waste
- Halogen free material reduces environmental impact in case of fire
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil for specific warranty details.
Available Now
The Cablofil Hot Dip Galvanised Steel Wire Cable Tray Support Rail 600mm is available for immediate purchase, ideal for industrial and commercial cable management applications.
