Trade Discount 20%
Cablofil Pre-Galvanised Steel Wire Cable Tray Cover | 50mm Width | 2000mm Length | Halogen Free | @Each of 1 | by Cablofil
Cablofil Pre-Galvanised Steel Wire Cable Tray Cover is designed for protecting wire mesh cable trays in industrial and commercial electrical installations. With a width of 50mm and a length of 2000mm, this cover features halogen-free materials for improved indoor air quality and corrosion resistance, making it ideal for environments that require durable and safe cable management solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: Pre-galvanised steel
- Cover width: 50 mm
- Length: 2000 mm
- Material thickness: 0.6 mm
- Surface protection: Continuously galvanised
- Operating temperature: -20°C to 120°C
- Storage temperature: -20°C to 120°C
- Halogen free: Yes
- Type of fastening: Cover clamp
- Suitable for: Wire mesh cable trays only
- Dimensions (H x L x W): 20mm x 2000mm x 50mm
- Weight: 2.5 kg
Key Features
- Pre-galvanised steel construction for corrosion resistance
- Cover width of 50mm and length of 2000mm
- Material thickness of 0.6mm
- Halogen free for safer indoor air quality
- Operating temperature range from -20°C to 120°C
- Can be fitted directly with integral tabs or with optional clips
- Suitable for wire mesh trays only
- Continuously galvanised surface protection
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with cable management systems to ensure secure fitting and compliance with safety standards.
Applications
- Suitable for wire mesh cable trays in industrial and commercial electrical installations
- Used to protect cables from dust and mechanical damage
- Ideal for environments requiring halogen-free materials and corrosion resistance
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Galvanised steel material extends product life reducing waste
- Halogen-free materials improve indoor air quality and reduce toxic emissions in case of fire
- Durable construction reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil for specific warranty details.
Available Now
The Cablofil Pre-Galvanised Steel Wire Cable Tray Cover 50mm x 2m Length is available for immediate purchase, ideal for protecting wire mesh cable trays in industrial and commercial electrical installations.
