Cablofil Pre-Galvanised Steel Wire Cable Tray Hold Down Clamp Plate | 1000 N Load Capacity | Corrosion Resistant | @Bag of 1 | by Cablofil
The Cablofil Pre-Galvanised Steel Wire Cable Tray Hold Down Clamp Plate is designed for securing steel wire cable trays in electrical installations. With a robust load-bearing capacity of 1000 N and corrosion-resistant pre-galvanised steel construction, it ensures durability and reliability in industrial and commercial applications. Ideal for use with 100 mm and 200 mm cable tray widths, this fixed clamp plate is essential for effective cable management.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Length: 58.5 mm
- Width: 50 mm
- Height: 3.5 mm
- Diameter: 8.5 mm
- Thread size (metric): 8
- Load bearing capacity: 1000 N
- Material: Steel
- Surface protection: Continuously galvanised
- Hinging: No
- Adjustable: No
- Suitable for circuit integrity: No
- Dimensions (H x L x W): 3.5mm x 58.5mm x 50mm
- Weight: 0.1 kg
Key Features
- Pre-galvanised steel construction for corrosion resistance
- Designed for use with 100 mm and 200 mm cable tray widths
- Load bearing capacity of 1000 N
- Electro-zinc surface protection for durability
- Non-adjustable, fixed clamp plate
Professional Installation Requirements
- Professional installation by qualified personnel is recommended to ensure secure and compliant cable tray fixing.
Applications
- Securing and holding down steel wire cable trays in electrical installations
- Suitable for use with 100 mm and 200 mm cable tray widths
- Industrial, commercial, and infrastructure cable management systems
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Pre-galvanised steel material extends product life and reduces need for frequent replacements
- Galvanised coating provides corrosion resistance, reducing environmental waste
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil or Legrand for specific warranty details.
Available Now
The Cablofil Pre-Galvanised Steel Wire Cable Tray Hold Down Clamp Plate CE40EZ is available for immediate purchase, ideal for securing steel wire cable trays in commercial and industrial electrical installations.
