Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail | Corrosion Resistant | S-Profile Shape | 1 kN Load Capacity | @Each of 1 | by Cablofil
The Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail is designed for reliable cable management in industrial and commercial settings. With a corrosion-resistant pre-galvanised steel construction and a robust S-profile shape, it supports a load capacity of 1 kN. Ideal for floor, wall, and trapeze mounting, this rail ensures secure installation and compliance with structural load requirements.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail | Corrosion Resistant | S-Profile Shape | 1 kN Load Capacity | @Each of 1 | by Cablofil
Brand: Cablofil
SKU: CM013300
Alternatively Known As: Steel Cable Tray Support Rail, Galvanised Cable Tray Rail, Wire Mesh Cable Tray Support
Technical Specifications
- Length: 294 mm
- Width: 68 mm
- Height: 25 mm
- Slit width: 25 mm
- Material thickness: 1.5 mm
- Profile shape: S-profile
- Model: Singular profile
- Type of perforation: Back perforated
- Hole width: 8.5 mm
- With toothing: No
- Snap-off: No
- Load bearing capacity: 1 kN
- Suitable for circuit integrity: No
- Material: Steel
- Material quality: Other
- Surface protection: Continuously galvanised
- Operating / setting temperature: -20 to 120 °C
- Storage temperature: -20 to 120 °C
- Halogen free: Yes
- Dimensions (H x L x W): 25mm x 294mm x 68mm
- Weight: 0.5 kg
Key Features
- Pre-galvanised steel construction for corrosion resistance
- S-profile shape with back perforation
- Load bearing capacity of 1 kN
- Halogen free material
- Operating temperature range from -20°C to 120°C
- Continuously galvanised surface protection
Professional Installation Requirements
- Professional installation by qualified personnel is recommended to ensure secure mounting and compliance with structural load requirements.
Applications
- Floor mounting for cable trays
- Wall mounting for cable trays
- Trapeze mounting for cable trays
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Pre-galvanised steel extends product life reducing replacement frequency
- Halogen free materials reduce environmental impact in case of fire
- Recyclable steel material supports sustainable construction practices
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil or Legrand for specific warranty details.
Available Now
The Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail 300mm is available for immediate purchase, ideal for industrial and commercial cable management applications.
