Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail | S-Profile Shape | Back Perforated | 1 kN Load Capacity | @Each of 1 | by Cablofil
The Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail is designed for versatile mounting options, including floor, wall, and trapeze installations. With a robust S-profile shape and back perforation, it offers a load-bearing capacity of 1 kN, making it ideal for industrial and commercial cable management applications. Its continuously galvanised surface ensures durability and halogen-free material enhances safety in case of fire.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail | S-Profile Shape | Back Perforated | 1 kN Load Capacity | @Each of 1 | by Cablofil
Brand: Cablofil
SKU: CM013200
Alternatively Known As: Steel Cable Tray Support Rail, Galvanised Cable Tray Rail, Wire Mesh Cable Tray Support
Technical Specifications
- Length: 194 mm
- Width: 68 mm
- Height: 25 mm
- Slit width: 25 mm
- Material thickness: 1.5 mm
- Profile shape: S-profile
- Model: Singular profile
- Type of perforation: Back perforated
- Hole width: 8.5 mm
- With toothing: No
- Snap-off: No
- Load bearing capacity: 1 kN
- Suitable for circuit integrity: No
- Material: Steel
- Material quality: Other
- Surface protection: Continuously galvanised
- Operating / setting temperature: -20 to 120 °C
- Storage temperature: -20 to 120 °C
- Halogen free: Yes
- Dimensions (H x L x W): 25mm x 194mm x 68mm
- Weight: 0.5 kg
Key Features
- Suitable for floor, wall, and trapeze mounting
- S-profile shape with back perforation
- Continuously galvanised surface protection
- Halogen free
- Load bearing capacity of 1 kN
- Operating temperature range from -20°C to 120°C
Professional Installation Requirements
- Installation should be performed by qualified professionals familiar with cable management systems to ensure secure mounting and compliance with safety standards.
Applications
- Floor mounting for cable trays
- Wall mounting for cable trays
- Trapeze mounting for cable trays
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Galvanised steel construction enhances durability and reduces the need for frequent replacements, minimizing waste.
- Halogen-free material contributes to safer environmental impact in case of fire.
Warranty Information
Standard manufacturer warranty applies; please refer to Cablofil or Legrand for specific warranty details.
Available Now
The Cablofil Pre-Galvanised Steel Wire Cable Tray Support Rail 200mm is available for immediate purchase, ideal for industrial and commercial cable management applications.
