Cantilever Bracket HDG | 300mm to 900mm | Heavy Duty Galvanised | Ezy Strut

BRAND: EzyStrut
SKU: CB4-300H
$39.50 List price: $47.80
+
Cantilever bracket with 300mm to 900mm range and heavy-duty galvanised finish—ideal for industrial and commercial cable support systems. Built for durability, with compliance to AS/NZS 1170 standards.

Product Name/Title: CB4-300H Cantilever Bracket HDG

Brand: Ezy Strut

SKU: CB4-300H

Alternatively Known As: Heavy Duty Cantilever Bracket, Galvanised Cantilever Bracket, Ezy Strut Bracket

Technical Specifications
  • Channel: E1000
  • Hole Diameter: 14mm
  • Hole Spacing: 20.5mm from end
  • Dimensions (H x L x W): 100mm x 900mm x 300mm
  • Weight: 2.5 kg
Key Features
  • 300mm through to 900mm braced cantilever bracket.
  • Manufactured to complement the range of cable support systems.
  • Fully galvanised after fabrication for heavy duty protection.
  • Available in stainless steel grade 316 for corrosive environments.
  • Fibreglass brackets available upon request.
Professional Installation Requirements
  • Professional installation is recommended to ensure proper support and safety.
Applications
  • Industrial: Cable support systems in various applications
  • Commercial: Suitable for use in commercial buildings and installations
Standards & Compliance
  • Complies with AS/NZS 1170 for structural design actions.
Environmental Benefits
  • Galvanised finish enhances longevity, reducing the need for replacements and waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The CB4-300H Cantilever Bracket HDG is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable cable support.
