Capacitive Proximity Sensor CQF16-06EPSEW1 | IP67, IP68, IP69K Rated | 0.5mm to 6mm Sensing Range | by SICK
The Capacitive Proximity Sensor CQF16-06EPSEW1 is designed for reliable detection of water-based liquids, featuring a sensing range of 0.5 mm to 6 mm and robust IP67, IP68, IP69K protection ratings. Ideal for industrial automation and process control, this sensor operates efficiently in temperatures from -25 °C to +80 °C, ensuring durability and performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V to 30 V DC
- Current consumption: 13 mA
- Voltage drop: ≤ 1.5 V DC
- Switching output: PNP, normally open
- Switching frequency: 10 Hz
- Sensing range: 0.5 mm to 6 mm
- Cable: PVC, 4-wire, 2 m length
- Protection rating: IP67, IP68, IP69K
- Shock resistance: 30 g, 11 ms
- Operating temperature: -25 °C to +80 °C
- Housing material: Plastic, PBT
- Short-circuit and power-up pulse protection included
- Dimensions (H x L x W): 34mm x 8mm x 16mm
- Weight: 0.1 kg
Key Features
- Rectangular housing with IP67, IP68, IP69K protection ratings
- Sensing range from 0.5 mm to 6 mm
- Flush and non-flush installation types
- Switching frequency of 10 Hz with PNP normally open output
- Cable connection type, 4-wire, 2 m length
- Short-circuit and power-up pulse protection
- Shock and vibration resistant (30 g, 11 ms)
- Wide ambient operating temperature range from -25 °C to +80 °C
- Plastic PBT housing material
- Teach-in adjustment for full or empty detection
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor setup and compliance with safety standards.
Applications
- Detection of water-based liquids with conductivity up to 50 mS/cm
- Suitable for containers with minimum diameter of 8 mm
- Plastic container thickness detection from 0.5 mm to 6 mm
- Glass container thickness detection from 0.5 mm to 4 mm
- Industrial automation and process control
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and electronic waste
- Energy-efficient operation minimizes power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK CQF16-06EPSEW1 Capacitive Proximity Sensor is available for immediate purchase, ideal for industrial automation and liquid detection applications.
