Capacitive Proximity Sensor M30 | 25mm Switching Distance | AC 20-250V | Plastic Housing by NHP

BRAND: NHP
SKU: EC3025TBAPL
$257.00 List price: $341.30
+
Capacitive proximity sensor with 25mm switching distance and AC 20-250V voltage—ideal for industrial automation and material handling. Built for durability, with a plastic housing and easy manual adjustment.

Product Name/Title: Carlo Gavazzi Capacitive Proximity Plastic M30 AC SCR NO NC Contacts 25mm 2m Prewired Cable

Brand: NHP

SKU: EC3025TBAPL

Alternatively Known As: Capacitive Proximity Switch, Proximity Sensor M30, AC Proximity Sensor

Technical Specifications
  • Switching distance: 25 mm
  • Voltage type: AC
  • Rated control supply voltage: 20-250 V
  • Switching frequency: 10 Hz
  • Max output current at protected output: 500 mA
  • Ambient temperature: -25-80 °C
  • Construction type housing: Cylinder, screw-thread
  • Material housing: Plastic
  • Dimensions (H x L x W): 30mm x 75.6mm x 30mm
  • Weight: 0.3 kg
Key Features
  • Capacitive proximity sensor with a switching distance of 25 mm.
  • Manual adjustment for easy configuration.
  • Programmable/configurable switch function.
Professional Installation Requirements
  • Professional installation by a qualified technician is recommended for optimal performance.
Applications
  • Industrial automation
  • Material handling
  • Packaging machinery
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Carlo Gavazzi Capacitive Proximity Sensor M30 AC SCR is available now for immediate purchase. Ideal for industrial automation and material handling applications.

Non-Returnable & Non-Cancellable

EC3025TBAPL-AU-Capacitive-Proximity-Sensor-Datasheet.pdf (EC3025TBAPL-AU-Capacitive-Proximity-Sensor-Datasheet.pdf, 260 Kb) [Download]
