Cat5E 10G STP Solid Cable Roll | 305m Length | Shielded Twisted Pair | Blue Jacket | by Electra Cables

SKU: CAT5E-BOXBLU
$154.00 List price: $204.19
+
Cat5E 10G STP Solid Cable Roll is perfect for high-speed structured cabling in both commercial and residential installations. With a length of 305 meters and shielded twisted pair construction, it supports data rates up to 10Gbps, ensuring reliable performance. The blue jacket allows for easy identification, making it an ideal choice for data centers, CCTV, and security systems.

Product Name/Title: Cat5E 10G STP Solid Cable Roll | 305m Length | Shielded Twisted Pair | Blue Jacket | by Electra Cables

Brand: Electra Cables

SKU: CAT5E-BOXBLU

Alternatively Known As: Cat5E Shielded Cable, Cat5E 10G Cable, Cat5E STP Cable, 305m Cat5E Roll, Blue Cat5E Network Cable, Electra Cat5E Cable

Technical Specifications
  • Category: Cat5E (Enhanced Category 5)
  • Cable Type: Shielded Twisted Pair (STP)
  • Conductor: Solid bare copper
  • Gauge: 24 AWG
  • Length: 305 meters (1000 feet) per roll
  • Jacket: PVC, Blue
  • Bandwidth: Up to 350 MHz
  • Data Rate: Supports up to 10Gbps Ethernet (10GBase-T)
  • Compliance: ANSI/TIA-568-C.2, ISO/IEC 11801
  • Packaging: Easy-pull dispensing box
  • Dimensions (H x L x W): 400mm x 400mm x 400mm
  • Weight: 10.5 kg
Key Features
  • 305m roll of solid core Cat5E cable for long-distance runs
  • Shielded Twisted Pair (STP) construction for superior EMI/RFI protection
  • Supports up to 10 Gigabit Ethernet speeds
  • Blue outer sheath for easy identification
  • Suitable for indoor structured cabling installations
  • Supplied in easy-pull box for tangle-free dispensing
Professional Installation Requirements
  • Installation by a qualified data cabling technician is recommended to ensure compliance with network standards and optimal performance.
Applications
  • Structured cabling for data networks in commercial and residential buildings
  • High-speed Ethernet connections (10/100/1000/10GBase-T)
  • Data centers and server rooms
  • CCTV and security system installations
  • Audio/Video transmission over network
Standards & Compliance
  • Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Long-lasting, high-quality materials reduce replacement frequency and electronic waste
  • Shielded design minimizes electromagnetic interference, supporting efficient network operation
Warranty Information

25-year manufacturer’s warranty for performance and material defects when installed as part of a certified system.

Available Now

The Electa Cat5E 10G STP Solid Cable Roll 305m in Blue is available for immediate purchase. Ideal for high-speed structured cabling in commercial and residential network installations.
