Cat6A Shielded Keystone Jack RJ45 10G White Pack of 24 Certech
Certech Cat6A Shielded RJ45 keystone jack features 10G, pack of 24. Ideal for data outlet and patch panel termination.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Dielectric Strength: 1000V RMS for 1min
- Insulation Resistance: 500MΩ min
- Contact Resistance: 20 mΩ per contact
- Temperature Range: -10°C to 60°C max
- Humidity: 10%-65%
- High impact plastic housing, Flame retardant UL 94V-0
- IDC Operating life: Minimum 250 Re-terminations
- Jack Operating life: Minimum 750 insertions
- Dimensions (H x L x W): 20mm x 50mm x 25mm
- Weight: 0.5 kg
Key Features
- Performance conforms to ANSI/TIA-568-C.2 Category 6A specification.
- Die-casting design for optimal EMI protection.
- Supports T568 A&B wiring.
- Tool-less design allows all 4 pairs to be mass terminated.
- Compact design ideal for high density applications.
- RoHS compliant.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and reliability.
Applications
- 10GBASE-T ETHERNET (IEEE P802.3an)
- 1000BASE-TX Fast Ethernet
- 1000BASE-T Gigabit Ethernet
- 100BASE-TX Fast Ethernet
- 155/622 Mbps ATM
- 100 Mbps TP-PMD
- 1.2Gb/s ATM
- 4/16 Mbps Token Ring
- 100VG-AnyLAN
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- RoHS compliant, reducing hazardous substances in electronic products.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Certech Cat6A RJ45 Shielded Tool-less Keystone Jack - 24pc Pack is available now for immediate purchase. Ideal for high-speed networking applications.
