Ceiling Motion Sensor Dual Tech Anti-Masking 360 Degree 20m Tecom
Tecom ceiling motion sensor features dual technology, anti-masking, 360 degree coverage and 20m range. Ideal for alarm systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Aritech DD669AM, 360° Ceiling Motion Detector, Dual PIR/Microwave Anti-Masking Sensor
Technical Specifications
- Detection Technology: Dual PIR and microwave
- Detection Range: 20 m diameter, selectable 20 m or 12 m
- Coverage: 360° or 180° selectable
- Microwave Frequency: 5.8 GHz
- Detection Curtains: 18
- Anti-Masking: Active anti-masking with dedicated relay
- Operating Voltage: 9–15 VDC, 12 VDC nominal
- Current Consumption: 19 mA
- Mounting Height: 2.5–5 m
- Operating Temperature: -10°C to +55°C
- Relative Humidity: Up to 95%, non-condensing
- Alarm Relay: Normally closed when energised
- Alarm Memory: Yes
- Environment: Indoor
- Security Grade: EN 50131 Grade 3
- Dimensions (H x L x W): 92mm x 138mm x 138mm
- Weight: 0.24 kg
Key Features
- Dual PIR and microwave detection technology
- 360° ceiling-mounted coverage with selectable 180° operation
- 20 m maximum detection diameter
- Active anti-masking reports attempts to obstruct the detector
- 18-curtain mirror-optic detection pattern
- Undercrawl protection for improved low-level detection
- 4D signal processing to help reduce nuisance alarms
- Selectable curtain masking for adapting coverage to the installation
- Range-controlled 5.8 GHz radar
- Suitable for flush ceiling mounting with the optional 360FM accessory
Professional Installation Requirements
- Installation, wiring and commissioning should be performed by a suitably qualified security-alarm technician. Configure the detector and alarm system in accordance with the manufacturer's instructions and applicable Australian requirements for intruder alarm installations.
Applications
- Commercial intruder alarm systems
- Residential security alarm systems
- Retail and office security
- Warehouses and other indoor protected areas
- High-security indoor installations requiring anti-masking detection
Standards & Compliance
- AS/NZS 2201.1:2007 — relevant requirements for the design, installation, commissioning and maintenance of intruder alarm systems
- AS 2201.3:1991 — relevant Australian standard for internal intruder alarm detection devices
Environmental Benefits
- Durable indoor electronic construction can support extended service life and reduce replacement waste
- Dual-technology processing and 4D signal discrimination can reduce nuisance alarms, potentially reducing unnecessary service call-outs
- Low-voltage 12 VDC operation supports integration with centralised alarm-system power supplies
Warranty Information
Tecom hardware is covered by a 5-year warranty from the date of manufacture, subject to the applicable manufacturer's warranty terms.
Available Now
Available through Tecom, Aritech and authorised Australian security-equipment distributors.
