'Centauri 230mm Shoplighter Tri-Colour 30W 0-10V White Haneco'

BRAND: Haneco
SKU: CENT230R-H10VD
$227.20 List price: $302.90
+ −
30 Days Return Electricians Unlock Trade Access
'Haneco Centauri 230mm shoplighter features tri-colour CCT, 30W 700mA driver and 0/1-10V power switchable dimming. Ideal for retail display lighting.'

Alternatively Known As: Haneco Centauri 230mm commercial downlight, LED shoplighter, recessed LED shoplight, 0-10V dimmable LED downlight

Technical Specifications
  • Product Code: CENT230R-H10VD
  • SAP Code: 7000301
  • Power: 30W
  • Driver: 0/1-10V dimmable, power-switchable
  • LED Input Current: 700mA
  • Colour Temperature: 3000K / 4000K / 5000K
  • Lumen Output: 3040lm / 3130lm / 3090lm
  • Efficacy: 101lm/W / 104lm/W / 103lm/W
  • Input Supply: 220-240V AC, 50/60Hz
  • Power Factor: >0.9
  • Beam Angle: 100°
  • Colour Rendering Index: CRI >80
  • Ingress Protection: IP44 front and body
  • IC Rating: IC-4 at Ta 25°C
  • Electrical Classification: Class 2
  • Rated Life: 50,000 hours at L70
  • Housing: Die-cast aluminium
  • Diffuser: Polycarbonate
  • Finish: White, RAL9003
  • Dimensions (H x L x W): 35mm x 230mm x 230mm
  • Weight: 1.2 kg
Key Features
  • Tri-colour selectable CCT for 3000K, 4000K or 5000K operation
  • 0/1-10V dimmable, power-switchable 30W driver
  • Low-profile recessed design for shallow ceiling spaces
  • Wide 100° beam angle for general and display lighting
  • IC-4 rated for covered and abutted installation conditions
  • IP44 protection from the front and body
  • Remote driver supplied with flex and plug
  • Suitable for retail, hospitality, office and commercial interiors
Professional Installation Requirements
  • Installation and connection to 220-240V mains wiring must be performed by a licensed electrician in accordance with the manufacturer's installation instructions and AS/NZS 3000. Install the recessed luminaire in accordance with applicable AS/NZS 60598 requirements and observe the IC-4 installation conditions.
Applications
  • Retail display lighting
  • Shopfronts and commercial interiors
  • Hospitality venues
  • Offices and meeting rooms
  • Hotel common areas
  • Hallways and entrance areas
  • General commercial recessed lighting
Standards & Compliance
  • AS/NZS 60598.1 - Luminaires: General requirements and tests
  • AS/NZS 60598.2.2 - Luminaires: Particular requirements for recessed luminaires
Environmental Benefits
  • LED technology provides lower energy consumption than conventional fluorescent and discharge lighting alternatives
  • 50,000-hour L70 rated life can reduce replacement frequency and maintenance waste
  • Aluminium housing is durable and recyclable at end of service life
  • Tri-colour and dimming functions allow light output and colour temperature to be matched to application requirements, supporting efficient operation
Warranty Information

5-year direct replacement warranty against manufacturing defects, subject to Haneco warranty terms and correct installation by a licensed electrician.

Available Now

Available through Haneco and authorised Australian electrical distributors.
