Changeover Switch 32A 1P DIN Rail NZK2 Chint
Chint NZK2 changeover switch features 32A rating, 1P configuration, 250V AC 50/60Hz and TH35 DIN rail mounting. Ideal for manual supply changeover in switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: CHINT NZK2-32 1P Changeover Switch, Manual Transfer Switch, Single-Pole Changeover Switch
Technical Specifications
- Model: NZK2-32/1
- Switch Type: Manual two-way changeover switch
- Number of Poles: 1P
- Switch Positions: I-II
- Rated Current: 32A
- Rated Voltage: 250V AC
- Rated Frequency: 50/60Hz
- Mounting: TH35-7.5 steel DIN rail
- Rated Making and Breaking Capacity: 1.1Ue, 1.25Ie, cos phi 0.3 ±0.05, 200 operations
- Operational Performance: Ue, Ie, cos phi 0.6 ±0.05, 10,000 operations
- Protection Rating: IP20
- Certification: KEMA approved
- Product Standard: IEC 60669-1
- Material: Insulated moulded electrical enclosure
- Dimensions (H x L x W): 85.3mm x 49.5mm x 18mm
- Weight: 0.1 kg
Key Features
- Manual transfer between two electrical circuits or power sources
- Single-pole configuration for switching one active conductor
- Compact one-module DIN rail format
- Suitable for installation alongside other modular switchboard devices
- Blue front operating lever with clear changeover positions
- Designed for residential, commercial and light industrial distribution panels
- Supports up to 10,000 operational cycles under specified conditions
Professional Installation Requirements
- Installation and connection should be performed by a licensed electrician in accordance with the manufacturer's instructions and AS/NZS 3000. Confirm suitability for the intended supply-changeover arrangement before installation.
Applications
- Manual mains-to-backup supply changeover
- Residential and commercial switchboards
- Generator and alternative-supply transfer arrangements
- Distribution boxes and control panels
- Low-voltage electrical and control circuits
Standards & Compliance
- AS/NZS 3000:2018 applies to installation and wiring in Australian electrical installations; product-specific manufacturer certification is to IEC 60669-1 rather than an Australian/New Zealand standard.
Environmental Benefits
- RoHS documentation supports restriction of specified hazardous substances
- Long operational life of up to 10,000 cycles can reduce replacement frequency and product waste
- Compact modular construction helps minimise switchboard installation space and material use
Warranty Information
CHINT warranty policy provides 27 months from the date of manufacture for other low-voltage apparatus sold through authorised channels, subject to applicable contract terms and Australian Consumer Law.
Available Now
Available through authorised CHINT distributors in Australia.
