Changeover Switch 32A 2P DIN Rail NZK2 Chint
Chint NZK2 changeover switch features 32A rating, 2P configuration, 250V AC 50/60Hz and TH35 DIN rail mounting. Ideal for manual supply changeover in switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: CHINT NZK2-32/2 Manual Transfer Switch, 2-Pole Changeover Switch, DIN Rail Source Changeover Switch
Technical Specifications
- Model: NZK2-32/2
- Switch Type: Manual two-position changeover switch
- Number of Poles: 2P
- Rated Current: 32A
- Rated Voltage: 250V AC
- Rated Frequency: 50/60Hz
- Positions: I / II
- Product Standard: IEC 60669-1
- Mounting: TH35-7.5 steel DIN rail
- Operating Temperature: -5°C to +40°C
- Permitted Mounting Inclination: ±5° from vertical
- Operational Performance: 10,000 operations
- Making and Breaking Performance: 200 operations at specified rated conditions
- Dimensions (H x L x W): 85.3mm x 65.5mm x 36mm
- Weight: 0.108 kg
Key Features
- Manual selection between two electrical supply sources
- Double-pole switching for simultaneous switching of active and neutral conductors where required by the installation design
- Compact two-module DIN rail format
- Suitable for modular switchboards and distribution panels
- Blue front operating handle with clear two-position selection
- Suitable for residential, commercial and light industrial applications
- KEMA-certified product series
- RoHS and REACH declarations available
Professional Installation Requirements
- Installation and connection to mains or generator circuits must be performed by a licensed electrician in accordance with the manufacturer's instructions, AS/NZS 3000 and applicable supply authority requirements. Where used with a generating set, AS/NZS 3010 requirements also apply.
Applications
- Manual changeover between mains and generator supplies
- Backup supply selection in residential switchboards
- Alternate supply selection in commercial distribution boards
- Lighting and control circuit source selection
- Small-load supply transfer in light industrial installations
Standards & Compliance
- AS/NZS 3000:2018 for selection, installation and wiring of low-voltage electrical equipment
- AS/NZS 3010:2017 where installed as part of a generating-set changeover system
- Manufacturer-declared product compliance with IEC 60669-1; verify local Australian approval and installation requirements before use
Environmental Benefits
- RoHS documentation supports restriction of certain hazardous substances
- REACH documentation supports chemical substance transparency and compliance
- Long operational life of up to 10,000 operations can reduce replacement frequency and electrical waste
- Compact DIN rail construction can reduce switchboard enclosure space and associated material use
Warranty Information
CHINT warranty policy indicates 27 months from the date of manufacture for other low-voltage apparatus supplied through authorised sales channels, subject to applicable warranty terms.
Available Now
Available through authorised CHINT distributors in Australia.
