Chassis EUREKA MCB 24P | 250A Current Rating | Flat Pan Design | Compatible with 18mm MCBs | by Tobin
The Chassis EUREKA MCB 24P is designed for reliable electrical distribution, featuring a robust flat pan design and a 250A current rating. Ideal for industrial and commercial applications, this chassis supports 24-pole miniature circuit breakers with an 18mm pole width, ensuring compatibility with Eureka 250A and 400A MCBs. Built for durability and efficiency, it complies with AS/NZS 3000 standards, making it a smart choice for your switchgear assemblies.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Chassis EUREKA MCB 24P | 250A Current Rating | Flat Pan Design | Compatible with 18mm MCBs | by Tobin
Brand: Tobin
SKU: ELS6-24-181
Alternatively Known As: EUREKA MCB Chassis 24P 250A, Flat Pan MCB Mounting Frame, 18mm Pole Width MCB Chassis
Technical Specifications
- Pole count: 24 poles
- Pole width: 18mm
- Current rating: 250A
- Type: Flat pan chassis
- Compatible with: Eureka 250A and 400A MCBs
- Short circuit rating: 6kA and 10kA options
- Dimensions (H x L x W): 100mm x 600mm x 450mm
- Weight: 3.5 kg
Key Features
- Flat pan type chassis design
- Compatible with 24-pole miniature circuit breakers (MCB)
- Supports 18mm pole width MCBs
- Rated for 250A current capacity
Professional Installation Requirements
- Installation should be performed by a licensed electrician experienced with switchgear assembly to ensure compliance with safety standards.
Applications
- Electrical switchgear assemblies
- Industrial and commercial electrical distribution panels
- Eaton Switchgear systems requiring Eureka 250A and 400A MCB chassis
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces need for frequent replacements, minimizing waste
- Supports efficient electrical distribution reducing energy losses
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Tobin Chassis EUREKA MCB 24P x 18mm 250A Flat pan type is available for immediate purchase, ideal for industrial and commercial electrical distribution applications.
