Circuit Breaker 1 Pole 4.5kA 16A | C Curve | Compact Design by Connected Switchgear
Circuit breaker with 4.5kA breaking capacity and 16A rating—ideal for commercial applications. Built for reliable circuit protection, with compact 18mm pole width and lockable toggles.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Circuit Breaker 1 Pole 4.5kA 16A
Brand: Connected Switchgear
SKU: MCB1416C
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Product Code: MCB1416C
- Voltage: 240V AC
- Amperage: 16A
- Power: 4.5kA
- Poles: 1 Pole
- Configuration: C Curve
- Approval: Energy Safe Victoria
- Dimensions (H x L x W): 85mm x 70mm x 18mm
- Weight: 0.5 kg
Key Features
- 4.5kA breaking capacity for effective overload and short circuit protection.
- 18mm pole width with ON/OFF indicators.
- Compatible with up to 25mm² cable and 35mm DIN rail mounting.
- Lockable toggles and pin/fork type busbar terminal connection.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Commercial: Ideal for various commercial applications requiring reliable circuit protection.
Standards & Compliance
- Complies with AS/NZS 60898.1 and AS/NZS 60947.2 for safety and performance standards.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
5 Year In House Warranty covering replacement and installation by an authorised electrician.
Available Now
The Circuit Breaker 1 Pole 4.5kA 16A is available now for immediate purchase. Ideal for commercial applications requiring reliable circuit protection.
