Circuit Breaker 3 Pole 10kA 6A | 415V AC | C Curve | Lockable Toggles by Connected Switchgear
Circuit breaker with 3 poles and 10kA breaking capacity—ideal for commercial and heavy industrial applications. Built for reliable circuit protection, with 415V AC voltage and lockable toggles for enhanced safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Circuit Breaker 3 Pole 10kA 6A
Brand: Connected Switchgear
SKU: MCB3106C
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Product Code: MCB3106C
- Voltage: 415V AC
- Amperage: 6A
- Power: 10kA
- Poles: 3 Pole
- Configuration: C Curve
- Approval: Energy Safe Victoria
- Dimensions (H x L x W): 90mm x 100mm x 54mm
- Weight: 0.5 kg
Key Features
- 10kA breaking capacity suitable for commercial and heavy industrial applications.
- 18mm pole width with ON/OFF indicators.
- Compatible with up to 25mm² cable and 35mm DIN rail mounting.
- Lockable toggles and pin/fork type busbar terminal connection.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Commercial: Heavy industrial applications requiring reliable circuit protection.
- General: Any application needing overload and short circuit protection.
Standards & Compliance
- Complies with AS/NZS 60898.1 and AS/NZS 60947.2 for safety and performance standards.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
5 years warranty covering replacement and installation by an authorised electrician.
Available Now
The Circuit Breaker 3 Pole 10kA 6A is available now for immediate purchase. Ideal for commercial and industrial applications requiring reliable circuit protection.
