Circuit Breaker 80A | Thermal-Magnetic Protection | 50kA Breaking Capacity | Adjustable Current Range | @Pack of 1 | by Clipsal
The Circuit Breaker 80A is designed for industrial motor protection and commercial electrical distribution. Featuring thermal-magnetic protection for overload and short-circuit, it offers an adjustable current range of 56–80A and a high breaking capacity of 50kA at 415V AC. Ideal for control panels and machinery, this breaker ensures reliable operation and safety in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Circuit Breaker 80A | Thermal-Magnetic Protection | 50kA Breaking Capacity | Adjustable Current Range | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHGV3ME80
Alternatively Known As: 80A Circuit Breaker, TeSys GV3ME80, Motor Protection Circuit Breaker, Clipsal 80A Breaker, Schneider GV3ME80
Technical Specifications
- Type: Thermal-magnetic circuit breaker
- Current rating: 56–80A adjustable
- Breaking capacity: 50kA at 415V AC
- Poles: 3
- Terminal type: Screw clamp
- Standards: IEC 60947-2, IEC 60947-4-1
- Operating voltage: Up to 690V AC
- Mounting: DIN rail or panel
- Trip class: 10A
- Dimensions (H x L x W): 130mm x 120mm x 55mm
- Weight: 0.7 kg
Key Features
- Thermal-magnetic protection for overload and short-circuit
- Adjustable current range: 56–80A
- Screw clamp terminals for secure connections
- Compact design for easy panel integration
- High breaking capacity for reliable operation
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with Australian standards and local regulations.
Applications
- Industrial motor protection
- Commercial electrical distribution boards
- Control panels
- Machinery and equipment requiring overload and short-circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal TeSys GV3ME80 80A Circuit Breaker is available for immediate purchase. Ideal for industrial and commercial motor protection and electrical distribution applications.
