Trade Discount 19%
Clip Cable 4mm 3C Flat | 450/750V Rated | PVC Insulation & Sheath | @Each of 1 | by Clipsal
The Clip Cable 4mm 3C Flat is designed for reliable electrical installations, featuring a 4mm² cross-sectional area and durable PVC insulation. Ideal for fixed wiring in residential, commercial, and industrial environments, this cable ensures safety and compliance with AS/NZS standards, making it a perfect choice for electricians and contractors.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Clip Cable 4mm 3C Flat | 450/750V Rated | PVC Insulation & Sheath | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: CLI564/2
Alternatively Known As: 4mm 3 Core Flat Cable, 3C 4mm Flat Electrical Wire, Clipsal Flat Power Cable, 3 Core Flat TPS Cable
Technical Specifications
- Conductor Size: 4mm²
- Number of Cores: 3
- Cable Type: Flat TPS (Thermoplastic Sheathed)
- Insulation: PVC
- Sheath: PVC
- Voltage Rating: 450/750V
- Maximum Current: 32A
- Operating Temperature: -15°C to 90°C
- Standard Length: 100m roll
- Dimensions (H x L x W): 5mm x 10000mm x 12mm
- Weight: 2.5 kg
Key Features
- 4mm² cross-sectional area for reliable current carrying capacity
- 3 core flat configuration for streamlined installation
- Durable PVC insulation and sheath for enhanced safety
- Suitable for fixed wiring in domestic, commercial, and industrial environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Residential: General power and lighting circuits
- Commercial: Office and retail electrical installations
- Industrial: Light-duty power distribution
Standards & Compliance
- Complies with AS/NZS 5000.2 for electric cables with thermoplastic insulation
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Long-lasting insulation reduces replacement frequency and waste
- PVC sheath is lead-free and compliant with RoHS standards
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal 4mm 3 Core Flat Electrical Cable is available for immediate purchase. Ideal for fixed wiring in residential, commercial, and light industrial installations.
