Clipsal CVS100F TM50D 3P3D MCCB | 100A Rated Current | 50kA Breaking Capacity | Thermal-Magnetic Trip | @Pack of 1 | by Clipsal
The Clipsal CVS100F TM50D 3P3D MCCB is designed for robust circuit protection with a 100A rated current and a 50kA breaking capacity, making it ideal for commercial and industrial electrical distribution. Featuring a thermal-magnetic trip unit, this circuit breaker ensures reliable overload and short-circuit protection, perfect for switchboards in factories and large buildings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Clipsal CVS100F TM50D 3P3D MCCB | 100A Rated Current | 50kA Breaking Capacity | Thermal-Magnetic Trip | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLV510334
Alternatively Known As: Clipsal MCCB 100A, CVS100F Circuit Breaker, 3 Pole 100A MCCB, SCHLV510334, Clipsal 3P3D MCCB
Technical Specifications
- Rated current: 100A
- Number of poles: 3
- Breaking capacity: 50kA at 415V AC
- Trip unit: Thermal-magnetic (TM50D)
- Mounting: Fixed
- Standards: IEC 60947-2 compliant
- Operating voltage: 415V AC
- Frequency: 50/60Hz
- Terminal type: Direct connection
- Dimensions (H x L x W): 165mm x 80mm x 105mm
- Weight: 2.5 kg
Key Features
- 100A rated current for robust circuit protection
- 3 pole, 3 direct connection design for three-phase systems
- 50kA breaking capacity for high fault current environments
- Thermal-magnetic trip unit for reliable overload and short-circuit protection
- Compact moulded case circuit breaker (MCCB) design
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution boards
- Main and sub-main circuit protection
- Switchboards in factories, warehouses, and large buildings
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables safe and efficient power distribution, reducing risk of electrical fires and equipment damage.
- Long operational life reduces replacement frequency and associated waste.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal CVS100F TM50D 3P3D MCCB (SCHLV510334) is available for immediate purchase. Ideal for commercial and industrial switchboards requiring high-capacity circuit protection.
