Clipsal Solis T Series Flush Switch | 1 Gang Toggle | 230V-240V | Polished White Ceramic | @Each of 1 | by Clipsal
The Clipsal Solis T Series Flush Switch is a 1 gang toggle switch designed for horizontal installation, operating at 230V-240V with a rated current of 20A. Ideal for both residential and commercial lighting control, this switch features a polished white ceramic finish for durability and aesthetic appeal. With screw terminal connections suitable for LEDi lamps up to 250W, it ensures reliable performance and compliance with AS/NZS 60669 standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated operational voltage: 230/240 V AC
- Rated current: 20 A/16 AX
- Load type: LEDi lamp 0-250 W
- Control type: Toggle switch
- Number of gangs: 1
- Device mounting: Flush
- Installation direction: Horizontal
- Connections: Screw terminals with clamping capacity 1.5 to 2.5 mm²
- Ambient operating temperature: 0 to 45 °C
- Relative humidity: 10 to 95%
- Material: Ceramic
- Surface finish: Polished white ceramic
- Cut-out dimensions: 93 x 50 mm
- Switch function: 1-pole 1/2-way
- Dimensions (H x L x W): 148mm x 56mm x 74mm
- Weight: 0.106 kg
Key Features
- Flush mount design with horizontal installation
- 1 gang toggle switch with 1-pole 1/2-way function
- Rated operational voltage of 230/240 V AC
- Rated current of 20 A/16 AX suitable for LEDi lamps up to 250 W
- Screw terminal connections with clamping capacity for 1.5 to 2.5 mm² wires
- Polished white ceramic surface finish for durability and aesthetic appeal
- Complies with AS/NZS 60669 standards
- Mercury free and RoHS compliant
Professional Installation Requirements
- Installation should be performed by a licensed electrician to ensure compliance with electrical safety standards and proper wiring.
Applications
- Residential: Lighting control in homes
- Commercial: Office and retail lighting control
- Industrial: General lighting control applications
Standards & Compliance
- AS/NZS 60669 – Switches for household and similar fixed electrical installations
Environmental Benefits
- Mercury free design reduces hazardous material use
- RoHS compliant ensuring reduced environmental impact
- Packaging made with recycled cardboard
Warranty Information
Standard Clipsal warranty applies, typically 2 years against manufacturing defects.
Available Now
The Clipsal Solis T Series Flush Switch Horizontal Mount 1 Gang 230V-240V 10AX in Platinum is available for immediate purchase, ideal for residential and commercial lighting control applications.
