Clipsal Solis T Series Flush Switch | 4 Gang | 1-Way/2-Way Function | 230V-240V | @Each of 1 | by Clipsal
The Clipsal Solis T Series Flush Switch features a sleek 4 gang design with 1-way/2-way functionality, perfect for both residential and commercial indoor applications. Rated for 230V-240V and capable of handling up to 20A, this polished platinum switch is not only stylish but also compliant with AS/NZS 60669 standards, ensuring safety and reliability in your electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated operational voltage: 230-240 V AC
- Rated current: 20 A / 16 AX
- Control type: Toggle switch
- Number of gangs: 4
- Switch function: 1-pole 1/2-way
- Connections: Screw terminals with clamping capacity 1.5 to 2.5 mm²
- Ambient operating temperature: 0 to 45 °C
- Relative humidity: 10 to 95%
- Material: Ceramic with polished surface finish
- Installation: Flush mount, horizontal orientation
- Cut-out dimensions: 130 x 50 mm
- Fixing center: 120 mm
- Network frequency: 50 Hz
- Load type: LEDi lamp 0 to 250 W
- Dimensions (H x L x W): 74mm x 56mm x 148mm
- Weight: 0.2 kg
Key Features
- Flush mount design with horizontal orientation
- 4 gang toggle switches with 1-way/2-way switching function
- Rated operational voltage of 230-240V AC
- Rated current of 20A/16AX suitable for LEDi lamps up to 250W
- Polished white ceramic surface finish with platinum color tint
- Screw terminal connections with clamping capacity for 1.5 to 2.5 mm² wires
- Complies with AS/NZS 60669 standards
- Mercury free and RoHS compliant
Professional Installation Requirements
- Installation should be performed by a licensed electrician to ensure compliance with electrical safety standards and proper wiring.
Applications
- Residential: Homes and apartments
- Commercial: Offices, retail spaces, hospitality venues
- General: Indoor electrical switching applications
Standards & Compliance
- Complies with AS/NZS 60669 for switches
Environmental Benefits
- Mercury free design reduces hazardous material use
- RoHS compliant ensuring reduced environmental impact
- Packaging made with recycled cardboard
Warranty Information
Standard Clipsal warranty applies, typically 2 years against manufacturing defects.
Available Now
The Clipsal Solis T Series Flush Switch 4 Gang Horizontal Mount in Platinum is available for immediate purchase, ideal for residential and commercial indoor electrical switching applications.
