Combination Screw Tap M6 | 3-in-1 Operation | SMART STEP Technology | by Wurth
The Combination Screw Tap M6 is designed for precision machining, featuring 3-in-1 operation for drilling, thread cutting, and countersinking in a single step. With SMART STEP technology, it enables up to 100% faster work than conventional taps, making it ideal for professionals working with steel, stainless steel, and titanium. Its innovative design ensures optimal centering on curved surfaces, providing a true-to-gauge through hole thread according to ISO 2 (6H).
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Combination Screw Tap M6 | 3-in-1 Operation | SMART STEP Technology | by Wurth
Brand: Wurth
SKU: 658580600
Alternatively Known As: Combination screw tap, SMART STEP screw tap, 3-in-1 thread cutter, M6 thread tap, high-speed combination tap
Technical Specifications
- Thread type x nominal diameter: M6
- Thread type: Metric thread
- Material to be processed: Steel, Cast metal, Stainless steel, Titanium, Non-ferrous metal
- Hole type: Clearance hole up to 2xD
- Quality: ZEBRA-Premium
- Suitable for machine type: Cordless screwdrivers, Drill, Pedestal drilling machine
- Pitch: 1.0 mm
- Length: 89 mm
- Shank diameter: 8.0 mm
- Size of square: 6.2 mm
- Cutting material: HSCo
- Surface: Vaporised
- Shank style: Combination of 3-face and cylinder shank with square drive
- Tolerance of screw taps: ISO 2 (6H)
- Service life rating: 4 of 4 points
- Trueness to gauge rating: 4 of 4 points
- Versatility rating: 4 of 4 points
- Cutting behaviour rating: 4 of 4 points
- Chip formation rating: 4 of 4 points
- Suitable for tensile strength up to: 1200 N/mm²
- Material sub-groups: General structural steels, Non-alloyed tempering steels, Alloyed tempering steels, Nitriding steels, Tool steels, High-speed steels, Cast iron, Ductile iron, Malleable cast iron, White cast iron, Stainless steels (various types), Titanium and alloys, Special alloys, Hardox, Spring steels, Aluminium and alloys, Copper, Brass, Bronze, Thermoset and thermoplastic plastics
- Dimensions (H x L x W): 89mm x 89mm x 8mm
- Weight: 0.1 kg
Key Features
- 3 in 1 operation: drilling, thread cutting, and countersinking/deburring in a single step
- SMART STEP technology enables up to 100% faster work than conventional taps
- Optimal centring on curved surfaces with high-precision circular holes
- Suitable for thicker workpieces up to 2xD material thickness
- Longer service life compared to conventional combination screw taps
- True-to-gauge through hole thread according to ISO 2 (6H)
- New shank design combining 3-flat and straight shank with square drive
- Product packaging made from 100% PCR recycled plastic and fully recyclable
- Exclusive availability from Wurth
Professional Installation Requirements
- Use with sufficient coolant and lubricant; suitable for use in cordless drill drivers, hand-held, pillar, and upright drills. Professional handling recommended for optimal results.
Applications
- Machining steel, cast metal, stainless steel, titanium, and non-ferrous metals
- Use in cordless screwdrivers, drills, and pedestal drilling machines
- Suitable for through hole threads in various materials
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Packaging made from 100% post-consumer recycled plastic and is fully recyclable, reducing environmental impact
Warranty Information
Warranty details available upon request from Wurth; typically covers manufacturing defects.
Available Now
The Wurth Premium Combination Screw Tap with SMART STEP Technology M6 is available for immediate purchase, ideal for precision machining and thread cutting applications in various metals.
