Compact AI Series 4CH PoE NVR | 16MP Resolution | AI Face Recognition & Human/Vehicle Detection | by Cornick
The Compact AI Series 4CH PoE NVR is designed for advanced CCTV surveillance, offering a maximum resolution of 16.0 megapixels and AI features like face recognition and human/vehicle detection. Ideal for residential and commercial security systems, this NVR supports up to 80Mbps incoming bandwidth and features a SATA HDD bay for up to 16TB of storage, ensuring reliable and efficient monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Compact AI Series 4CH PoE NVR | 16MP Resolution | AI Face Recognition & Human/Vehicle Detection | by Cornick
Brand: Cornick
SKU: NVR4COM-I
Alternatively Known As: 4 Channel AI PoE Network Video Recorder, AI NVR with HDD Bay, PoE CCTV NVR, AI Surveillance NVR
Technical Specifications
- Max Resolution: 16.0 Megapixels (4920 x 3264)
- Incoming Bandwidth: 80Mbps
- Decoding Capability: 4CH@8MP/25fps (AI disabled), 4CH@5MP/25fps (AI enabled)
- AI Features: Face recognition (1 channel), Human/Vehicle detection (2-4 channels), ANPR (4 channels)
- Storage: 1 x SATA HDD bay, up to 16TB
- Network: Built-in 4 port PoE switch
- Video Output: HDMI and VGA simultaneous output
- Backup: External USB device or local network
- Dimensions (H x L x W): 45mm x 180mm x 220mm
- Weight: 1.5 kg
Key Features
- Records up to 16.0 megapixel resolution (4920 x 3264)
- Supports up to 80Mbps total incoming bandwidth
- Decodes 4 channels at 8MP/25fps with AI disabled
- Decodes 4 channels at 5MP/25fps with AI enabled
- AI face recognition and database comparison on 1 channel
- AI human/vehicle detection via tripwire/intrusion on 2 channels
- AI human/vehicle detection via motion detection on 4 channels
- Supports ANPR (automatic number plate recognition) on up to 4 channels
- 1 SATA HDD bay supporting up to 16TB capacity
- Built-in 4 port Power over Ethernet (PoE) switch
- Simultaneous HDMI and VGA video output
- Backup footage via external USB device or local network
Professional Installation Requirements
- Professional installation by a qualified CCTV technician or electrician is recommended to ensure proper network configuration and power supply setup.
Applications
- CCTV surveillance for residential properties
- Commercial security systems
- Small to medium business surveillance
- AI-enhanced security monitoring
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient PoE technology reduces power consumption by combining data and power transmission over a single cable.
- Supports remote backup reducing the need for physical media and waste.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Cornick Compact AI Series 4CH PoE NVR with 1 x HDD Bay is available now for immediate purchase. Ideal for upgrading existing CCTV systems or new AI-enabled surveillance installations.
