COMPACTBLOCK LDX I O Expansion Module 16 Digital Inputs 24V DC Screw Terminal Connections by Allen-Bradley

BRAND: Allen-Bradley
SKU: 1790T16BV0X
$1,169.10 List price: $1,456.90
+ −
30 Days Return Electricians Unlock Trade Access
The COMPACTBLOCK LDX I/O Expansion Module features 16 digital inputs, operating at 24V DC, making it ideal for industrial automation systems. With secure screw terminal connections, this module ensures reliable integration into existing control systems, enhancing manufacturing process control and factory automation.

Alternatively Known As: I/O Expansion Module, Digital Input Expansion, COMPACTBLOCK LDX 16DI Module

Technical Specifications
  • Input Type: 16 Digital Inputs
  • Input Voltage: 24V DC
  • Connection Type: Screw terminals
  • Module Type: I/O Expansion
  • Compatible with COMPACTBLOCK LDX systems
  • Dimensions (H x L x W): 50mm x 120mm x 100mm
  • Weight: 1.2 kg
Key Features
  • 16 digital inputs (DI) for expanded control capabilities
  • Operates at 24V DC
  • Screw terminal connections for secure wiring
  • Compact design for easy integration into existing systems
Professional Installation Requirements
  • Installation should be performed by a qualified electrician or automation technician to ensure compliance with electrical standards and system integration.
Applications
  • Industrial automation systems requiring digital input expansion
  • Manufacturing process control
  • Machine control panels
  • Factory automation and monitoring
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Supports efficient automation reducing energy waste
  • Durable design minimizes replacement frequency and electronic waste
Warranty Information

Standard manufacturer warranty of 1 year against defects.
