Conduit U Clip PVC 32mm Grey Box of 50 Tripac

BRAND: CABAC
SKU: CLIP32-P
$0.40 List price: $0.60
+ −
30 Days Return Electricians Unlock Trade Access
Tripac PVC conduit U clip features 32mm size, grey colour and tongue and groove clip-on design for side-by-side runs. Ideal for discreet conduit mounting.

Alternatively Known As: PVC conduit saddle clip, conduit fixing clip, conduit mounting clip, CLIP32-P

Technical Specifications
  • Nominal Conduit Size: 32 mm
  • Material: Polyvinyl chloride (PVC)
  • Colour: Grey
  • Packaging: Box of 50 clips
  • Design: Tongue-and-groove clip-on system
  • Temperature Range: -5°C to 60°C
  • UV Resistance: Yes
  • Flame Retardant: Yes
  • Environmental Certification: BEP certified
  • Dimensions (H x L x W): 45mm x 55mm x 12mm
  • Weight: 0.45 kg
Key Features
  • Discreet conduit mounting where visible screws are undesirable
  • Tongue-and-groove design permits side-by-side conduit runs
  • Suitable for wall, ceiling, metal beam and timber beam mounting
  • UV-stabilised PVC construction for improved resistance to environmental conditions
  • Supplied as a box of 50
Applications
  • Mounting 32 mm electrical conduit
  • Side-by-side conduit installations
  • Wall and ceiling conduit runs
  • Conduit mounting to metal beams
  • Conduit mounting to timber beams
Standards & Compliance
  • AS/NZS 3000:2018 – relevant installation requirements for electrical wiring systems and conduit support
  • AS/NZS 2053 series – applicable conduit and fittings standard for compatible electrical conduit systems; verify the specific project requirement
Environmental Benefits
  • PVC construction can be recovered through the Tripac PVC Take-Back Program, which accepts clean used Tripac PVC fittings for reuse or recycling
  • Durable UV-stabilised material can help extend service life and reduce replacement waste
  • BEP environmental compliance certification is stated for the product
Warranty Information

Specific warranty duration is not published for CLIP32-P. Product warranty is subject to the Cabac/Tripac terms and conditions and should be confirmed with the distributor.

Available Now

Available through Cabac and authorised Australian electrical wholesalers and distributors.
