Contact Crimp Pins 16mm² | 150A Current Rating | IP55 Ingress Protection | Quick Release by Ausproof
Contact crimp pins rated for 150A with IP55 ingress protection—ideal for mining and hazardous environments. Built for reliable electrical connections, featuring a quick release mechanism and durable stainless steel construction.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PS 12 / 68 Contact Crimp Pins 16mm^2
Brand: Ausproof
SKU: RS2363
Alternatively Known As: PS Range 150A plugs, PS 12/68 Crimp Pins, Flameproof Electrical Connectors, Ex-certified contact pins
Technical Specifications
- Voltage Range: 660 to 1,100V
- Current Rating: 150A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests of 12.5kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests of 4.0kA for 0.2 seconds
- AC High Voltage Withstand (Phase): 4.2kV for one minute
- AC High Voltage Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Rated for 150A
- Compliant to: AS/NZS 1299, IEC 60079-0, IEC 60079-1
- Dimensions (H x L x W): 200mm x 250mm x 150mm
- Weight: 7.9 kg
Key Features
- Quick Release mechanism
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Installation should be performed by a qualified electrician experienced with Ex-certified equipment and hazardous area installations.
Applications
- Mining and tunnelling operations
- Commercial electrical installations
- Group 1 hazardous environments requiring flameproof equipment
Standards & Compliance
- Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres
Environmental Benefits
- Durable stainless steel construction reduces replacement frequency and waste
- Flameproof repairable design minimizes environmental impact by extending product life
Warranty Information
Standard manufacturer warranty applies. Please contact Ausproof for detailed warranty terms.
Available Now
The Ausproof PS 12 / 68 Contact Crimp Pins 16mm² are available now for immediate purchase. Ideal for mining, tunnelling, and hazardous environment electrical connections.
