Contact Crimp Pins 70mm² | 150A Current Rating | IP55 Ingress Protection | Quick Release by Ausproof
Contact crimp pins rated for 150A with IP55 ingress protection—ideal for mining and hazardous environments. Built for professional installation, these stainless steel connectors ensure reliable performance and easy termination.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PS 12 / 68 Contact Crimp Pins 70mm^2
Brand: Ausproof
SKU: RS1615
Alternatively Known As: Ex-certified contact crimp pins, 150A plugs and receptacles, flameproof electrical connectors
Technical Specifications
- Voltage: 660 to 1,100V
- Current Rating: 150A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 Tests of 12.5kA for 0.2 seconds
- Through Fault Current (Earth): 2 Tests of 4.0kA for 0.2 seconds
- AC HV Withstand (Phase): 4.2kV for one minute
- AC HV Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: 150A
- Compliant to: AS/NZS 1299, IEC 60079-0, IEC 60079-1
- Dimensions (H x L x W): 200mm x 300mm x 150mm
- Weight: 7.9 kg
Key Features
- Quick Release
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Professional installation by qualified electricians trained in hazardous area equipment is required to ensure safety and compliance.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements.
- Flameproof repairability minimizes waste and environmental impact.
Warranty Information
Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.
Available Now
The Ausproof PS 12 / 68 Contact Crimp Pins 70mm² are available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications.
