Home/Electrical/Industrial/Industrial Inlet Socket/Contact Pin & Insulation Set 4P | 25 mm² | IP55 Rated | Quick Release by Ausproof

Trade Discount 19%

$PL 16 \ 78 Contact Pin & Insul Set 4P 25 mm^2$

Contact Pin & Insulation Set 4P | 25 mm² | IP55 Rated | Quick Release by Ausproof

BRAND: Ausproof

SKU: RS1999

$270.90 List price: $336.40

+ −

30 Days Return Delivery Options

Contact pin and insulation set with 25 mm² capacity and IP55 rating—ideal for mining and hazardous environments. Built for safety and reliability, featuring quick release and stainless steel construction for durability.

Description

Product Name/Title: PL 16 \ 78 Contact Pin & Insul Set 4P 25 mm^2

Brand: Ausproof

SKU: RS1999

Alternatively Known As: PL Range Contact Pin Set, Ex-rated Contact Pin 4P, Flameproof Contact Pin Set 25 mm²

Technical Specifications

Voltage Range: 660V to 3300V
Current Ratings: 300A and 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Weight: 10.7 kg (Receptacle)
Dimensions (H x L x W): 150mm x 200mm x 150mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation must be performed by qualified personnel trained in handling Ex-rated electrical equipment to ensure safety and compliance with hazardous area regulations.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Flameproof repairability reduces waste by allowing on-site repairs without full replacement.

Warranty Information

Warranty details available upon request from Ausproof, typically covering manufacturing defects.

Available Now

The Ausproof PL 16 \ 78 Contact Pin & Insul Set 4P 25 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring robust and flameproof electrical connections.
