Contact Pin & Insulation Set 4P | 660V to 3300V | 300A to 425A | IP55 by Ausproof
Contact pin and insulation set with a voltage range of 660V to 3300V and current ratings from 300A to 425A—ideal for mining and hazardous environments. Built for safety and compliance, featuring durable stainless steel construction and quick release for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PL 16 \ 106 Contact Pin & Insul Set 4P 120 mm^2
Brand: Ausproof
SKU: RS2123
Alternatively Known As: PL Range Contact Pin Set, Flameproof Contact Pin Set, Ex-rated Contact Pin 4P, Mining Contact Pin Set
Technical Specifications
- Voltage Range: 660V to 3300V
- Current Ratings: 300A to 425A
- Material: Stainless Steel
- Ingress Protection: IP55
- Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
- Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
- AC HV Withstand (Phase): 8.6kV for one minute
- AC HV Withstand (Pilot): 1.0kV for one minute
- Temperature Rise: Rated for 300A and 425A
- Weight: 10.7 kg (Receptacle), 9.0 kg (Plug)
- Dimensions (H x L x W): 120mm x 120mm x 120mm
- Weight: 10.7 kg
Key Features
- Quick Release
- Single piece contacts to prevent hot joints
- Easy termination
- Easy flameproof repair
- Full solid earth connectivity throughout product
- Full phase to phase segregation with earth
- Lightest Ex product on the market
- Silicone Protection Cover
- Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles
Professional Installation Requirements
- Professional installation by qualified personnel trained in hazardous area electrical equipment is required to ensure safety and compliance.
Applications
- Mining
- Tunnelling
- Commercial applications
- Group 1 hazardous environments
Standards & Compliance
- Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres
Environmental Benefits
- Durable stainless steel construction reduces need for frequent replacements.
- Flameproof design enhances safety, reducing risk of environmental hazards.
Warranty Information
Warranty details available upon request from Ausproof; typically includes coverage against manufacturing defects.
Available Now
The Ausproof PL 16 \ 106 Contact Pin & Insul Set 4P 120 mm² is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring flameproof electrical connectors.
