Contactor 4KW 3 Pole 48VAC | Compact DIN Rail Mountable | High Electrical Endurance | by Clipsal
The Contactor 4KW 3 Pole 48VAC is designed for reliable industrial motor control and power switching. With a robust 4kW power rating and a compact DIN rail mountable design, it ensures high electrical endurance for frequent switching applications. Ideal for HVAC systems, lighting circuits, and pumps, this contactor is built to meet AS/NZS 60947 standards, making it a dependable choice for commercial and industrial environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Contactor 4KW 3 Pole 48VAC | Compact DIN Rail Mountable | High Electrical Endurance | by Clipsal
Brand: Clipsal
SKU: SCHLC1K0910E7
Alternatively Known As: 4kW 3 Pole Contactor, 48VAC Coil Contactor, Industrial Motor Contactor, Clipsal SCHLC1K0910E7, Schneider LC1K0910E7
Technical Specifications
- Rated operational power: 4kW (AC-3, 400V)
- Number of poles: 3
- Coil voltage: 48VAC 50/60Hz
- Rated operational current: 9A (AC-3, 400V)
- Auxiliary contacts: 1 NO
- Mounting: DIN rail or screw
- Electrical endurance: 1,000,000 cycles
- Mechanical endurance: 10,000,000 cycles
- Operating temperature: -5°C to +60°C
- Degree of protection: IP20
- Dimensions (H x L x W): 80mm x 80mm x 45mm
- Weight: 0.3 kg
Key Features
- 4kW power rating at 400V (AC-3)
- 3 pole configuration for three-phase applications
- 48VAC coil voltage
- Compact DIN rail mountable design
- High electrical and mechanical endurance
- Reliable operation for frequent switching
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations and standards.
Applications
- Industrial motor control
- Lighting circuits
- HVAC systems
- Pumps and compressors
- General power switching in commercial and industrial environments
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear.
Environmental Benefits
- Enables efficient energy management by providing reliable switching for motors and lighting.
- Durable design reduces replacement frequency and electronic waste.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Contactor 4KW 3 Pole 48VAC (SCHLC1K0910E7) is available for immediate purchase. Ideal for industrial and commercial motor control and power switching applications.
