Contactor 80A 4P 240V | Heavy-Duty 4NO Configuration | AC-1 Utilization | by Clipsal
The Contactor 80A 4P 240V is designed for heavy-duty applications, featuring a robust 80A rated current and a versatile 4NO configuration. Ideal for industrial motor control, lighting circuits, and HVAC systems, this contactor ensures reliable performance with a 240V AC coil suitable for 50/60Hz operation. Built for durability and efficiency, it meets AS/NZS standards, making it a perfect choice for commercial and industrial environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Contactor 80A 4P 240V | Heavy-Duty 4NO Configuration | AC-1 Utilization | by Clipsal
Brand: Clipsal
SKU: SCHLC1D80004U7
Alternatively Known As: 80A 4 Pole Contactor, TeSys D 80A Contactor, Clipsal 4P Contactor 240V, LC1D80004U7, Industrial Power Contactor
Technical Specifications
- Rated operational current: 80A (AC-3), 125A (AC-1)
- Number of poles: 4 (4NO)
- Coil voltage: 240V AC 50/60Hz
- Utilization category: AC-1/AC-3
- Rated operational voltage: up to 690V
- Conforms to IEC 60947-4-1
- Mechanical durability: 10 million operations
- Electrical durability: 1 million operations (AC-1)
- Mounting: DIN rail or screw fixing
- Auxiliary contacts: Optional add-on
- Dimensions (H x L x W): 120mm x 130mm x 105mm
- Weight: 1.2 kg
Key Features
- 80A rated current for heavy-duty applications
- 4 pole (4NO) configuration for versatile switching
- AC-1 utilization category up to 440V 125A
- 240V AC coil suitable for 50/60Hz operation
- TeSys D series reliability and performance
- Compact design for easy panel integration
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Industrial motor control
- Lighting circuits
- HVAC systems
- Pumping stations
- General power switching in commercial and industrial environments
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3820 for essential safety requirements for electrical equipment
Environmental Benefits
- Durable construction extends product lifespan, reducing replacement frequency and waste.
- Efficient switching reduces energy losses in control circuits.
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal TeSys D Contactor 80A 4P 240V 50/60Hz is available for immediate purchase. Ideal for industrial and commercial power switching applications.
