Contactor Auxiliary Contact Block 1NO 1NC to Suit NCH8 Chint

BRAND: CABAC
SKU: 242934
$28.70 List price: $38.20
+ −
30 Days Return Electricians Unlock Trade Access
Chint NCF8 auxiliary contact block features 1NO+1NC contacts and side-mount fitting to suit NCH8 modular contactors. Ideal for status signalling and interlocking.

Alternatively Known As: NCH8 auxiliary contact, AX-11/11, 1NO+1NC side auxiliary contact, CHINT NCF8-11 auxiliary contact block

Technical Specifications
  • Contact Configuration: 1NO + 1NC
  • Mounting Type: Side-mounted auxiliary contact block
  • Compatible Contactor Series: CHINT NCH8 modular contactors
  • Rated Insulation Voltage Ui: 500 V
  • Rated Impulse Withstand Voltage Uimp: 4 kV
  • Utilisation Category AC-12: 240 V, 5 A
  • Utilisation Category AC-15: 230 V, 2 A
  • Utilisation Category DC-13: 130 V, 1 A
  • Terminal Capacity: 1.5–6 mm²
  • Terminal Screw Torque: 0.8 N·m
  • Dimensions (H x L x W): 81mm x 66mm x 9mm
  • Weight: 0.1 kg
Key Features
  • Provides one normally open and one normally closed auxiliary contact
  • Side-mounting configuration for NCH8 modular contactors
  • Suitable for contactor status indication and electrical interlocking
  • Supports AC and DC control-circuit applications
  • Compact accessory design for modular switchboards and control panels
Professional Installation Requirements
  • Installation and wiring should be performed by a licensed electrician with the supply isolated, in accordance with the contactor manufacturer’s instructions and applicable Australian wiring requirements.
Applications
  • Contactor status signalling
  • Electrical interlocking between contactors
  • Control panels and switchboards
  • Building services and modular distribution boards
  • Pump, lighting, heating and motor-control circuits
Standards & Compliance
  • AS/NZS IEC 60947.5.1:2015 for electromechanical control circuit devices and auxiliary contacts
Environmental Benefits
  • Extends the functional life of compatible contactors by adding signalling and interlocking capability without replacing the main device
  • Compact construction reduces material use compared with installing a separate control relay
  • Metal electrical components can be recovered through appropriate electrical equipment recycling
Warranty Information

CHINT warranty policy generally covers other low-voltage apparatus against defects in materials and workmanship for 27 months from the date of manufacture when purchased through authorised sales channels; contractual terms may vary.

Available Now

Available through authorised CHINT distributors in Australia.
