Contactor CTX3 3P 265A | 380V-450V AC | 5 Million Operations | by Legrand
The Contactor CTX3 3P 265A is engineered for reliable industrial motor control, supporting up to 265A for AC-3 applications and 300A for resistive loads. With screw terminals for easy connections and a robust design ensuring up to 5 million mechanical operations, it's perfect for demanding environments. Ideal for qualified electricians, this contactor meets stringent safety standards and is compatible with all Legrand CTX3 auxiliaries.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Contactor CTX3 3P 265A | 380V-450V AC | 5 Million Operations | by Legrand
Brand: Legrand
SKU: 416309
Alternatively Known As: Legrand CTX3 Motor Contactor, 3 Pole Contactor 265A, Industrial Motor Contactor, Legrand 3P Contactor
Technical Specifications
- Rated operation current AC-3 (400V): 265A
- Rated operation power AC-3 (400V): 147 kW
- Rated operation current AC-1 (400V): 300A
- Rated operation current AC-4 (400V): 200A
- Rated operation power AC-4 (400V): 102 kW
- Rated control supply voltage AC 50/60 Hz: 323-418 V
- Number of main contacts: 3 normally open
- Number of auxiliary contacts: 2 normally open + 2 normally closed
- Electrical connection: Screw terminals
- Endurance: 5 million mechanical, 1 million electrical operations
- Operation cycles per hour (AC-3): 1200
- Dimensions (H x L x W): 120mm x 110mm x 90mm
- Weight: 3.5 kg
Key Features
- Rated current 265A for AC-3 motor switching
- Switches resistive loads up to 300A (AC-1)
- Screw terminals for power (95mm² to 240mm²) and coil/auxiliary circuits (1.25mm² to 5.5mm²)
- Equipped with 2NO + 2NC auxiliary contacts, including mirror contact compliant with IEC 60947-4-1
- Endurance up to 5 million mechanical and 1 million electrical operations
- Supports up to 1200 operation cycles per hour (AC-3)
- Removable front cover for visual inspection of arc chambers and contacts
- Engineered for easy coil replacement
- Compatible with all Legrand CTX3 auxiliaries and accessories
Professional Installation Requirements
- Installation must be performed by a qualified electrician following Legrand installation instructions and local electrical codes.
Applications
- Industrial motor control and protection
- Tertiary installations for switching inductive and non-inductive loads
- Switching of 3-phase motors up to 147 kW at 415V
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Designed with an environmentally conscious process complying with substance-restriction requirements
- Long operational life reduces waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; typically 1-2 years against manufacturing defects.
Available Now
The Legrand Contactor CTX3 3P 265A 380V-450V AC is available for immediate purchase, ideal for industrial and tertiary motor control applications.
