Contactor CTX3 3P 630A | 200V-240V AC | 2NO + 2NC Auxiliary Contacts | Endurance 2 Million Operations | @EA of 1 | by Legrand
The Contactor CTX3 3P 630A is engineered for robust industrial motor control, supporting 3-phase motors up to 330 kW with a rated current of 630A. Featuring 2 normally open and 2 normally closed auxiliary contacts, this contactor ensures reliable operation with an impressive endurance of up to 2 million mechanical cycles. Ideal for tertiary and industrial applications, it’s designed for easy installation and compliance with local electrical standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Contactor CTX3 3P 630A | 200V-240V AC | 2NO + 2NC Auxiliary Contacts | Endurance 2 Million Operations | @EA of 1 | by Legrand
Brand: Legrand
SKU: 416346
Alternatively Known As: Motor Contactor 3P 630A, Legrand CTX3 Contactor, Industrial Motor Contactor, 3-Phase Contactor
Technical Specifications
- Rated control supply voltage AC 50 Hz: 170-264 V
- Rated control supply voltage AC 60 Hz: 170-264 V
- Rated control supply voltage DC: 170-242 V
- Voltage type for actuating: AC/DC
- Number of normally open main contacts: 3
- Number of normally closed main contacts: 0
- Rated operation current Ie at AC-1, 400 V: 660 A
- Rated operation current Ie at AC-3, 400 V: 630 A
- Rated operation power at AC-3, 400 V: 330 kW
- Rated operation current Ie at AC-4, 400 V: 400 A
- Rated operation power at AC-4, 400 V: 200 kW
- Number of auxiliary contacts normally open: 2
- Number of auxiliary contacts normally closed: 2
- Type of electrical connection of main circuit: Screw connection
- Endurance: up to 2 million mechanical and 0.5 million electrical operations
- Operation cycles (AC-3) per hour: 1200
- Dimensions (H x L x W): 200mm x 180mm x 150mm
- Weight: 5 kg
Key Features
- Rated current 630A (AC-3) for 3-phase motors up to 330 kW
- Resistive loads up to 660A (AC-1)
- 2NO + 2NC auxiliary contacts with NC mirror contact per IEC 60947-4-1
- Endurance up to 2 million mechanical and 0.5 million electrical operations
- Number of operation cycles (AC-3) per hour: 1200
- Removable front cover for visual inspection of arc chambers and contacts
- Engineered for easy coil replacement
- Screw connection for main circuit
Professional Installation Requirements
- Installation should be performed by a qualified electrician familiar with industrial motor control equipment and compliant with local electrical standards.
Applications
- Tertiary and industrial installations
- Switching of 3-phase motors up to 330 kW (415V)
- Switching of inductive and non-inductive loads
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Designed with substance-restriction compliance and environmentally conscious manufacturing process
Warranty Information
Standard manufacturer warranty applies; please refer to Legrand for specific warranty terms.
Available Now
The Legrand Contactor CTX3 3P 630A 200V-240V AC / 200V-220V DC is available for immediate purchase, ideal for industrial and tertiary motor control applications.
