Contactor CTX3 4P 100A 230V AC | 4 Normally Open Contacts | 12 Million Mechanical Operations | by Legrand

BRAND: Legrand
SKU: 416446
$544.90 List price: $679.00
+ −
30 Days Return Delivery Options
The Contactor CTX3 4P 100A 230V AC is engineered for reliable motor control in industrial environments, featuring 4 normally open contacts and a rated current of 100A for switching resistive loads. With an impressive endurance of up to 12 million mechanical operations, it's perfect for tertiary and industrial electrical installations, ensuring compliance with safety standards and efficient operation.

Product Name/Title: Contactor CTX3 4P 100A 230V AC | 4 Normally Open Contacts | 12 Million Mechanical Operations | by Legrand

Brand: Legrand

SKU: 416446

Alternatively Known As: Motor Contactor 4 Pole 100A 230V AC, Legrand CTX3 Contactor, Industrial Motor Contactor

Technical Specifications
  • Rated control supply voltage AC 50 Hz: 195.5-253 V
  • Rated control supply voltage AC 60 Hz: 195.5-253 V
  • Voltage type for actuating: AC
  • Number of normally closed contacts as main contact: 0
  • Number of normally open contacts as main contact: 4
  • Type of electrical connection of main circuit: Cable clamp
  • Rated operation current Ie at AC-1, 400 V: 100 A
  • Rated operation current Ie at AC-3, 400 V: 65 A
  • Rated operation power at AC-3, 400 V: 30 kW
  • Number of auxiliary contacts as normally open contact: 0
  • Number of auxiliary contacts as normally closed contact: 0
  • Suitable for distribution board: Yes
  • Dimensions (H x L x W): 85mm x 70mm x 45mm
  • Weight: 1.5 kg
Key Features
  • Rated current 100A for switching resistive loads (AC-1)
  • Screw terminals capacity: Power 2 x 16mm² to 35mm², Coil 0.75mm² to 2.5mm²
  • Endurance up to 12 million mechanical operations and 1 million electrical operations
  • Number of operation cycles (AC-1) per hour: 1800
  • Compatible with all Legrand CTX3 auxiliaries and accessories
  • Designed with environmentally conscious process and substance-restriction compliance
  • Possible fixing on 35 mm 'top hat' mounting rail (IEC 60715) and mounting plate
  • Engineered for easy coil replacement
Professional Installation Requirements
  • Professional installation by a qualified electrician is required to ensure compliance with electrical safety standards and proper operation.
Applications
  • Tertiary and industrial electrical installations
  • Switching of inductive and non-inductive loads
  • Motor control and protection in industrial environments
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Designed with substance-restriction compliance to reduce environmental impact
  • Manufactured using environmentally conscious processes
Warranty Information

Standard manufacturer warranty applies, typically 1-2 years depending on region and usage conditions.

Available Now

The Legrand Contactor CTX3 4P 100A 230V AC is available for immediate purchase, ideal for industrial and tertiary motor control applications.
