Contactor CTX3 4P 60A 230V AC | 4 Normally Open Contacts | Screw Terminals | Endurance 15 Million Operations | @EA of 1 | by Legrand

BRAND: Legrand
SKU: 416436
$289.90 List price: $361.30
+ −
30 Days Return Delivery Options
Contactor CTX3 4P 60A 230V AC is engineered for reliable motor control in industrial and tertiary applications. With 4 normally open contacts and a rated current of 60A, it efficiently switches both inductive and non-inductive loads. Designed for easy installation and compliance with environmental standards, this contactor ensures long-lasting performance with an endurance of up to 15 million mechanical operations.

Product Name/Title: Contactor CTX3 4P 60A 230V AC | 4 Normally Open Contacts | Screw Terminals | Endurance 15 Million Operations | @EA of 1 | by Legrand

Brand: Legrand

SKU: 416436

Alternatively Known As: Motor Contactor 4 Pole 60A 230V AC, Legrand CTX3 Contactor, Industrial Motor Contactor

Technical Specifications
  • Rated control supply voltage AC 50 Hz: 195.5-253 V
  • Rated control supply voltage AC 60 Hz: 195.5-253 V
  • Voltage type for actuating: AC
  • Number of normally closed contacts as main contact: 0
  • Number of normally open contacts as main contact: 4
  • Type of electrical connection of main circuit: Cable clamp
  • Rated operation current Ie at AC-1, 400 V: 60 A
  • Rated operation current Ie at AC-3, 400 V: 40 A
  • Rated operation power at AC-3, 400 V: 18.5 kW
  • Number of auxiliary contacts as normally open contact: 0
  • Number of auxiliary contacts as normally closed contact: 0
  • Suitable for distribution board: Yes
  • Dimensions (H x L x W): 85mm x 70mm x 45mm
  • Weight: 0.5 kg
Key Features
  • Rated current 60A for switching resistive loads
  • Screw terminals capacity: Power 2 x 10mm² to 16mm², Coil 0.75mm² to 2.5mm²
  • Compatible with all Legrand CTX3 auxiliaries and accessories
  • Endurance up to 15 million mechanical operations and 1 million electrical operations
  • Number of operation cycles (AC-1) per hour: 1800
  • Designed with environmentally conscious process and substance-restriction compliance
  • Possible fixing on 35 mm 'top hat' mounting rail (IEC 60715) and mounting plate
  • Reduced size to optimize cabinet space
  • Engineered for easy coil replacement
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and safety.
Applications
  • Tertiary and industrial electrical installations
  • Switching of inductive and non-inductive loads
  • Motor control and protection in distribution boards
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Designed with substance-restriction compliance to reduce environmental impact
  • Manufactured using environmentally conscious processes
Warranty Information

Standard manufacturer warranty applies; please refer to Legrand for specific warranty terms.

Available Now

Legrand Contactor CTX3 4P 60A 230V AC is available for immediate purchase, ideal for industrial and tertiary motor control applications.
