Contactor CTX3 Mini 3P 12A 1NC 230V AC | 5.5 kW Motor Switching | Compact Design | @EA of 1 | by Legrand

BRAND: Legrand
SKU: 417056
$68.00 List price: $84.80
+ −
30 Days Return Delivery Options
The Contactor CTX3 Mini 3P 12A 1NC 230V AC is designed for efficient motor control, capable of switching 3-phase motors up to 5.5 kW. With a compact design and 1 normally closed auxiliary contact, it's perfect for industrial and tertiary applications. Built for durability, it offers up to 12 million mechanical operations, ensuring reliable performance in demanding environments.

Product Name/Title: Contactor CTX3 Mini 3P 12A 1NC 230V AC | 5.5 kW Motor Switching | Compact Design | @EA of 1 | by Legrand

Brand: Legrand

SKU: 417056

Alternatively Known As: Mini Contactor, Motor Contactor 12A, 3 Pole Contactor, CTX3 Contactor

Technical Specifications
  • Rated control supply voltage AC 50/60 Hz: 195.5-253 V
  • Number of main contacts: 3 normally open (NO), 0 normally closed (NC)
  • Number of auxiliary contacts: 1 normally closed (NC)
  • Rated operation current AC-1 (400 V): 20 A
  • Rated operation current AC-3 (400 V): 12 A
  • Rated operation power AC-3 (400 V): 5.5 kW
  • Type of electrical connection: Cable clamp
  • Endurance: 12 million mechanical operations, 1 million electrical operations
  • Operation cycles per hour (AC-3): 1800
  • Dimensions (H x L x W): 80mm x 70mm x 45mm
  • Weight: 0.3 kg
Key Features
  • Rated current 12A (AC-3) for 3-phase motor switching up to 5.5 kW
  • Resistive load switching up to 20A (AC-1)
  • 1 normally closed auxiliary contact (NC) compliant with IEC 60947-4-1
  • Screw terminals for power, coil, and auxiliary circuits
  • Endurance up to 12 million mechanical and 1 million electrical operations
  • Supports up to 1800 operation cycles per hour (AC-3)
  • Compact size for optimized cabinet space
  • Mounting on 35 mm 'top hat' rail (IEC 60715) or mounting plate
  • Environmentally conscious design and substance-restriction compliant
Professional Installation Requirements
  • Installation by a qualified electrician is recommended to ensure compliance with electrical standards and safety.
Applications
  • Tertiary and industrial installations
  • Switching of inductive and non-inductive loads
  • Control of 3-phase motors up to 5.5 kW (415V)
  • Use in distribution boards
Standards & Compliance
  • AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Designed with environmentally conscious processes
  • Complies with substance-restriction requirements to reduce hazardous materials
Warranty Information

Standard manufacturer warranty applies; please refer to Legrand for specific warranty terms.

Available Now

The Legrand Contactor CTX3 Mini 3P 12A 1NC 230V AC is available for immediate purchase, ideal for industrial and tertiary motor control applications.
