Contactor CTX3 Mini 4P 16A 24V DC | 4 Normally Open Contacts | High Durability | Compact Design | @Each of 1 | by Legrand

BRAND: Legrand
SKU: 417141
$82.90 List price: $103.30
+ −
30 Days Return Delivery Options
The Contactor CTX3 Mini 4P 16A 24V DC is designed for efficient motor control and protection in industrial and tertiary electrical installations. With 4 normally open contacts and a high durability rating of up to 12 million mechanical operations, this compact contactor is perfect for switching inductive and non-inductive loads. Its cable clamp connection ensures reliable performance, making it an ideal choice for distribution boards.

Product Name/Title: Contactor CTX3 Mini 4P 16A 24V DC | 4 Normally Open Contacts | High Durability | Compact Design | @Each of 1 | by Legrand

Brand: Legrand

SKU: 417141

Alternatively Known As: Mini Contactor 4 Pole 16 Amp 24V DC, CTX3 Mini Motor Contactor, Legrand 4P Contactor 16A

Technical Specifications
  • Rated control supply voltage: 20.4-26.4 V DC
  • Voltage type for actuating: DC
  • Number of normally open contacts: 4
  • Number of normally closed contacts: 0
  • Rated operation current Ie at AC-1, 400 V: 20 A
  • Rated operation current Ie at AC-3, 400 V: 16 A
  • Rated operation power at AC-3, 400 V: 7.5 kW
  • Screw terminals capacity: Power 2 x 1.25mm² to 2mm², Coil 0.75mm² to 2.5mm²
  • Number of operation cycles: up to 12 million mechanical, 1 million electrical
  • Number of operation cycles per hour (AC-3): 1800
  • Type of electrical connection: Cable clamp
  • Mounting: 35 mm top hat rail (IEC 60715) or mounting plate
  • Dimensions (H x L x W): 70mm x 60mm x 45mm
  • Weight: 0.3 kg
Key Features
  • Rated control supply voltage: 20.4-26.4 V DC
  • 4 normally open main contacts
  • Rated operation current: 20A (AC-1), 16A (AC-3) at 400V
  • Rated operation power: 7.5 kW at AC-3, 400V
  • High durability: up to 12 million mechanical and 1 million electrical operations
  • Compact size for optimized cabinet space
  • Screw terminals capacity: Power 2 x 1.25mm² to 2mm², Coil 0.75mm² to 2.5mm²
  • Cable clamp electrical connection for main circuit
  • Suitable for mounting on 35 mm 'top hat' rail (IEC 60715) or mounting plate
Professional Installation Requirements
  • Installation should be performed by a qualified electrician following the product instructions and using only Legrand branded accessories.
Applications
  • Tertiary and industrial electrical installations
  • Switching of inductive and non-inductive loads
  • Motor control and protection in distribution boards
Standards & Compliance
  • AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Designed with an environmentally conscious process
  • Complies with substance-restriction requirements to reduce hazardous materials
Warranty Information

Standard manufacturer warranty applies. Please refer to Legrand's official warranty policy for details.

Available Now

The Legrand Contactor CTX3 Mini 4P 16A 24V DC is available for immediate purchase, ideal for industrial and tertiary motor control applications.
