Contactor CTX3 Mini 4P 16A 415V AC | High Durability | Compact Size | Screw Terminals | @EA of 1 | by Legrand

BRAND: Legrand
SKU: 417149
$92.40 List price: $115.20
1 EA ($92.40 per EA)
+ −
30 Days Return Delivery Options
The Contactor CTX3 Mini 4P 16A 415V AC is designed for reliable motor control in industrial and tertiary applications. With a high durability rating of up to 12 million mechanical operations and a compact design for optimized cabinet space, this contactor is perfect for switching inductive and non-inductive loads. Installation by a qualified electrician ensures compliance with safety standards, making it a dependable choice for your electrical installations.
Technical Specifications
  • Rated control supply voltage AC 50/60 Hz: 352.75-456.5 V
  • Number of normally open contacts: 4
  • Number of normally closed contacts: 0
  • Type of electrical connection: Cable clamp
  • Rated operation power at AC-3, 400 V: 7.5 kW
  • Number of operation cycles per hour (AC-3): 1800
  • Dimensions (H x L x W): 70mm x 60mm x 45mm
  • Weight: 0.3 kg
Key Features
  • Rated operation current: 20A (AC-1), 16A (AC-3) at 400V
  • High durability with up to 12 million mechanical and 1 million electrical operations
  • Compact size for optimized cabinet space
  • 4 normally open main contacts
  • Screw terminals for power and coil connections
  • Suitable for mounting on 35 mm 'top hat' rail or mounting plate
Professional Installation Requirements
  • Installation by a qualified electrician is required to ensure compliance with electrical safety standards and proper operation.
Applications
  • Tertiary and industrial electrical installations
  • Switching of inductive and non-inductive loads
  • Motor control and protection in distribution boards
Standards & Compliance
  • Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
  • Designed with substance-restriction compliance and environmentally conscious manufacturing processes
Warranty Information

Standard manufacturer warranty applies; please refer to Legrand for specific warranty terms.

Available Now

Legrand Contactor CTX3 Mini 4P 16A 415V AC is available for immediate purchase, ideal for industrial and tertiary motor control applications.

F02017FR-05 (F02017FR-05_.pdf, 619 Kb) [Download]

LE07420AB (LE07420AB.pdf, 4,661 Kb) [Download]

F02017EN-05 (F02017EN-05.pdf, 641 Kb) [Download]

Technical Guide: Protection and control of 3-phase asynchronous motors (EXB19046_TG_3phase-asynchronous-motors_EN.pdf, 5,963 Kb) [Download]

ex223001_0280 (ex223001_0280.pdf, 90 Kb) [Download]

ex223001_0281 (ex223001_0281.pdf, 66 Kb) [Download]
