Contactor ICT 25A 4NC | 220-240V 50Hz | Remote Control | IP20 by Clipsal
Contactor with 25A current and 220-240V 50Hz voltage—ideal for residential and small commercial motor, heating, and lighting control. Built for durability with remote control capability and IP20 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Acti9, Contactor, ICT 25A 4NC 220...240V 50Hz
Brand: Clipsal
SKU: A9C20837
Alternatively Known As: Acti9 Contactor, ICT Contactor, 25A Contactor
Technical Specifications
- Rated operational voltage: 220-240 V AC 50 Hz
- Control signal type: maintained
- Maximum power: 1.6 W at 400 V AC
- Rated insulation voltage: 500 V AC 50/60 Hz
- Rated impulse withstand voltage: 4 kV
- Switching frequency: 100 switching operations/day
- Hold-in power consumption: 4.6 VA
- Inrush power: 34 VA
- Total power losses: 4.2 W
- Noise level: 30 dB
- Pollution degree: 2
- Operating altitude: 2000 m
- Dimensions (H x L x W): 81mm x 60mm x 36mm
- Weight: 0.236 kg
Key Features
- Rated operational current: 25 A AC-7A
- Remote control capability
- Mechanical durability of 1,000,000 cycles
- Electrical durability of 100,000 cycles
- IP20 protection rating
- Compatible with 35 mm symmetrical DIN rail mounting
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Small commercial applications requiring motor, heating, and lighting control.
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Complies with IEC/EN 61095 standards for safety and performance.
Warranty Information
18 months warranty against manufacturing defects.
Available Now
The Clipsal Acti9 Contactor ICT 25A 4NC 220-240V is available now for immediate purchase. Ideal for residential and small commercial applications.
