Contacts Block | 1NO Configuration | Snap-On Mounting | 600V AC Rated | @Pack of 1 | by Clipsal
The Contacts Block features a 1NO (Normally Open) configuration and snap-on mounting, making it perfect for industrial control panels and automation systems. Designed for easy installation with screw terminal connections, this block ensures high electrical durability and compliance with IEC standards, providing reliable operation in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Contacts Block | 1NO Configuration | Snap-On Mounting | 600V AC Rated | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLADN22P
Alternatively Known As: Auxiliary Contact Block, 1NO Contact Block, 22mm Contact Block, Clipsal Contact Block, SCHLADN22P
Technical Specifications
- Contact Configuration: 1NO (Normally Open)
- Mounting: Snap-on for 22mm pushbutton stations
- Terminal Type: Screw terminals
- Rated Operational Voltage: 600V AC
- Rated Current: 10A
- Material: High-grade plastic and metal contacts
- Standards: IEC 60947-5-1 compliant
- Dimensions (H x L x W): 40mm x 20mm x 30mm
- Weight: 0.1 kg
Key Features
- 1 Normally Open (1NO) contact configuration
- 22mm diameter for compatibility with standard pushbutton stations
- Snap-on mounting for easy installation
- High electrical durability for industrial environments
- Screw terminal connections for secure wiring
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with safety standards.
Applications
- Industrial control panels
- Machinery and automation systems
- Switchboards
- Electrical enclosures
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable construction reduces replacement frequency and waste.
- Reliable operation helps maintain energy-efficient control systems.
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal SCHLADN22P Contacts Block is available for immediate purchase. Ideal for industrial control panels, automation systems, and electrical enclosures.
