Control Circuit Breaker | 10A Rated Current | 2 Pole Design | DIN Rail Mountable | @Pack of 1 | by Clipsal
The Control Circuit Breaker is designed for reliable circuit protection with a 10A rated current and a 2 pole design, ensuring enhanced safety and isolation. Ideal for industrial control panels and commercial electrical installations, this compact DIN rail mountable breaker offers quick installation and robust performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Control Circuit Breaker | 10A Rated Current | 2 Pole Design | DIN Rail Mountable | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHGB2CB10
Alternatively Known As: Clipsal 10A Control Circuit Breaker, SCHGB2CB10, 2 Pole MCB, Control MCB, Clipsal Miniature Circuit Breaker
Technical Specifications
- Rated current: 10A
- Number of poles: 2
- Mounting: DIN rail
- Breaking capacity: 6kA
- Voltage rating: 240/415V AC
- Tripping curve: C
- Operating temperature: -25°C to +55°C
- Dimensions (H x L x W): 80mm x 70mm x 36mm
- Weight: 0.15 kg
Key Features
- 10A rated current for reliable circuit protection
- 2 pole design for enhanced safety and isolation
- Compact DIN rail mountable construction
- Quick and easy installation
- Robust build for industrial environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local regulations and standards.
Applications
- Industrial control panels
- Automation systems
- Switchboards
- Motor control centers
- Commercial electrical installations
Standards & Compliance
- Complies with AS/NZS 60947.2 for circuit breakers
Environmental Benefits
- Enhances electrical safety, reducing risk of electrical fires and equipment damage.
- Long operational life reduces replacement frequency and waste.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHGB2CB10 Control Circuit Breaker is available for immediate purchase. Ideal for industrial and commercial electrical control and protection applications.
