Trade Discount 25%
Control Relay 110VAC Coil | 3NO 1NC Contacts | 20A 690V | DIN-Rail by NHP
Control relay with 110VAC coil and 3NO 1NC contact configuration—ideal for industrial automation and commercial HVAC systems. Built for high performance, with 20A 690V rating and efficient power consumption.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 700-CF Control Relay 110VAC Coil 3NO 1NC Contact
Brand: NHP
SKU: 700CF310D
Alternatively Known As: Control Relay, 700-CF Relay, Allen-Bradley Relay
Technical Specifications
- Number of Auxiliary Contacts (NO): 3
- Number of Auxiliary Contacts (NC): 1
- Rated Operation Current (Ie) at 400 V: 20 A
- Max Rated Operation Voltage (Ue) AC: 690 V
- Voltage Type for Actuating: AC
- Control Supply Voltage (Us) at AC 50 Hz: 120 V
- Power Consumption AC Coil Pickup: 75 VA
- Power Consumption AC Coil Hold-in: 9.5 VA
- Control Supply Voltage (Us) at AC 60 Hz: 120 V
- Mounting Method: DIN-rail/screw
- Connection Type Auxiliary Circuit: Screw connection
- Dimensions (H x L x W): 81mm x 86.5mm x 45mm
- Weight: 0.39 kg
Key Features
- 3 Normally Open (NO) and 1 Normally Closed (NC) contact configuration.
- Rated for operation at 20 A and 690 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation and control systems
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient power consumption reduces energy waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 700-CF Control Relay 110VAC Coil 3NO 1NC Contact is available now for immediate purchase. Ideal for industrial and commercial applications.
Non-Returnable & Non-Cancellable
