Control Relay 12VDC Coil | 4NO Contacts | 10A Rated | DIN-Rail by NHP
Control relay with 12VDC coil and 4 normally open contacts—ideal for automation systems and control panels. Built for industrial and commercial use, with 10A operation and efficient power consumption.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CS8 Relay 12VDC Coil 4NO Contact
Brand: NHP
SKU: CS8C40E12VDC
Alternatively Known As: Control Relay, Mini Relay, 12V Relay
Technical Specifications
- Number of Auxiliary Contacts (NO): 4
- Rated Operation Current (Ie 400 V): 10 A
- Max Rated Operation Voltage (UE AC): 690 V
- Voltage Type for Actuating: DC
- Control Supply Voltage (Us at DC): 12 V
- Power Consumption DC Coil Pickup: 3 W
- Power Consumption DC Coil Hold In: 3 W
- Mounting Method: DIN-rail/screw
- Connection Type Auxiliary Circuit: Screw connection
- Dimensions (H x L x W): 56mm x 53mm x 45mm
- Weight: 0.2 kg
Key Features
- Mini control relay with 4 normally open contacts.
- Rated for 10 A operation at 400 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring relay control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient power consumption reduces energy waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Relay 12VDC Coil 4NO Contact is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable control.
