Control Relay 24VAC Coil 2NO 2NC Contacts 20A Rated NHP
Control relay with 24VAC coil and 2NO 2NC contacts—ideal for industrial automation and commercial HVAC systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Number of Auxiliary Contacts (NO): 2
- Number of Auxiliary Contacts (NC): 2
- Rated Operation Current (Ie) at 400 V: 20 A
- Max Rated Operation Voltage (Ue) AC: 690 V
- Voltage Type for Actuating: AC
- Control Supply Voltage (Us) at AC 50 Hz: 24 V
- Power Consumption AC Coil Pickup: 75 VA
- Power Consumption AC Coil Hold-in: 9.5 VA
- Mounting Method: DIN-rail/screw
- Connection Type Auxiliary Circuit: Screw connection
- Dimensions (H x L x W): 81mm x 86.5mm x 45mm
- Weight: 0.39 kg
Key Features
- 2 Normally Open (NO) and 2 Normally Closed (NC) contacts.
- Rated operation current of 20 A at 400 V.
- Control supply voltage of 24 V AC.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, machinery control
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient operation reduces power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS7 Control Relay 24VAC Coil 2NO 2NC Contact is available now for immediate purchase. Ideal for industrial and commercial control applications.
