Control Relay 415VAC Coil | 3NO 1NC | Compact Design | IP20 Rated by NHP
Control relay with 415VAC coil, featuring 3 normally open and 1 normally closed contact—ideal for industrial automation and commercial HVAC systems. Built for easy installation with screw connections and compact design, offering IP20 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CS8 Relay 415VAC Coil 3NO 1NC Contact
Brand: NHP
SKU: CS831Z415VAC
Alternatively Known As: Control Relay, Mini Relay, Switching Relay
Technical Specifications
- Nominal Current: 6 A
- Number of Normally Closed Contacts: 3
- Number of Normally Open Contacts: 1
- Voltage Type for Actuating: AC
- Control Supply Voltage (50Hz): 415 V
- Control Supply Voltage (60Hz): 415 V
- Type of Electric Connection: Screw connection
- Degree of Protection: IP20
- Dimensions (H x L x W): 100mm x 75mm x 50mm
- Weight: 0.5 kg
Key Features
- Control relay mini with compact design.
- Screw connection for easy installation.
- IP20 rated for protection against solid objects.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Relay 415VAC Coil 3NO 1NC Contact is available now for immediate purchase. Ideal for industrial and commercial control applications.
Non-Returnable & Non-Cancellable
